Hanwha XNP-C7310R RB Overview
The Hanwha XNP-C7310R RB is a fixed dome network camera designed for outdoor surveillance in demanding environments. This Rebox-platform camera combines 4MP resolution at 30 fps with a powerful 31x motorized zoom lens (6.91mm–214.64mm), making it suitable for wide-area monitoring and detailed target acquisition in a single device. Built on the WN7 architecture with integrated AI engine, the camera delivers intelligent video analytics, adaptive infrared illumination to 300 meters, and extreme wide dynamic range (120dB) for high-contrast scenes.
Hanwha XNP-C7310R RB Key Features
- 4MP Resolution at 30 fps — Full HD+ capture with H.265, H.264, and MJPEG codec support for flexible bandwidth and storage optimization via WiseStream III intelligent compression.
- 31x Optical Zoom with Motorized Varifocal Lens (6.91–214.64mm) — Enables pan-and-scan identification from wide overview to narrow detail shots without additional cameras, reducing deployment footprint and cost.
- Wise AF Intelligent Autofocus — Automatic focus adjustment ensures sharp imagery across the full zoom range without manual calibration or focus drift in varying lighting conditions.
- Adaptive Wise IR with 300m Range — Dynamic infrared illumination adjusts intensity based on scene depth and target distance, preventing washout in near-field and delivering extended range capability for perimeter surveillance and low-light intrusion detection.
- Extreme WDR 120dB with Day/Night ICR — Handles high-contrast scenes (direct sunlight against dark shadows) while maintaining color fidelity in day mode and switching to monochrome IR mode at night for optimal sensitivity and noise reduction.
- AI-Powered Object Detection and Tracking — Built-in WN7 AI engine enables real-time detection of persons, faces, vehicles, and license plates with automatic object tracking and target lock for continuous monitoring of moving subjects.
- Advanced Virtual Line and Area Analytics — Detect crossing events, directional movement (intrusion/exit), loitering, and presence in designated zones; defocus, motion, tampering, fog, and audio detection trigger events for comprehensive scene awareness.
- IP66 and IK10 Rated with Lens Heater — Fully sealed against dust and high-pressure water spray; vandal-resistant to extreme impact; integrated lens heater removes water and snow buildup for year-round outdoor reliability from –50°C to +55°C (–58°F to +131°F).
- PoE++ (802.3bt) Powered with Included Injector — Single Ethernet cable delivers power and data; bundled PoE++ injector simplifies deployment without external power supplies or complex wiring.
- FIPS 140-2, NEMA4X, and NEMA-TS 2 Compliance — Cryptographic module certification and environmental/electrical standards ensure secure operation in critical infrastructure, telecommunications, and outdoor industrial settings.
- Noise and Sound Classification with I/O Box Support — Compatible with SPM-4210 network I/O box (sold separately) for alarm relays, audio input/output, and fog horn integration without direct wiring to camera.
Hanwha XNP-C7310R RB Integration and Compatibility
The XNP-C7310R RB supports standard protocols including IPv4, IPv6, TCP/IP, UDP, RTP, RTSP, HTTP/HTTPS, DHCP, DNS, and LLDP. Integration with third-party VMS platforms and control systems is enabled via standard ONVIF conformance and Hanwha's SUNAPI HTTP API. The camera is compatible with the SPM-4210 Network I/O Box for extended alarm and audio connectivity without requiring direct connections to the camera location. Network security includes 802.1X authentication (EAP-TLS, EAP-LEAP), device certificates signed by Hanwha Techwin Root CA, IP address filtering, and user access logging.
Hanwha XNP-C7310R RB Package Contents
- Hanwha XNP-C7310R RB Fixed Dome Camera
- PoE++ Injector
- HPoE Injector
