i-PRO WV-X22600-V2L Overview
The i-PRO WV-X22600-V2L is a 6MP indoor vandal-resistant dome network camera built for mission-critical surveillance in institutional and commercial environments. This X-series camera combines a 1/1.8-inch CMOS sensor with integrated AI processing capability, enabling real-time edge analytics without external GPU dependencies. Engineered for high-security deployments, it delivers forensic-grade low-light performance, robust encryption, and NDAA compliance in a compact IK10-certified dome housing.
i-PRO WV-X22600-V2L Key Features
- 6MP Resolution with 1/1.8-inch CMOS Sensor — Captures fine detail across a 7.68 mm × 4.32 mm scanning area, delivering resolution sufficient for facial identification and evidence-grade recording in corridors, lobbies, and perimeter zones.
- On-Device AI Engine Supporting Up to 9 Analytics Apps — Runs edge-based intelligent video analytics directly on the camera without relying on external servers, reducing latency and improving operational resilience. Compatible with AI on-site learning for custom model development.
- Extreme Low-Light Performance — Achieves 0.04 lx color sensitivity (30 IRE, F1.5, 1/30s, AGC:11) and 0 lx in black-and-white mode with IR LED active, ensuring clear imaging in near-complete darkness.
- Maximum 132 dB Dynamic Range with Super Dynamic Technology — Intelligently manages extreme backlighting and high-contrast scenes, maintaining detail in both shadow and highlight regions simultaneously without washout or blocking.
- H.265 and H.264 Compression — Dual codec support with adaptive bitrate control reduces bandwidth consumption by up to 50% compared to H.264-only cameras while maintaining forensic image quality.
- IK10 Vandal Certification — Rated for impact resistance up to 50 joules, meeting IK10 standard for environments where deliberate tampering, forced entry, or rough handling poses a risk.
- FIPS 140-2 Level 3 Secure Element — Integrates NXP EdgeLock SE050F hardware security module, providing cryptographic key storage, secure boot, and tamper detection to prevent firmware manipulation and unauthorized access.
- NDAA Compliance — Meets U.S. Department of Defense vendor restrictions, qualifying for federal, state, and local government procurement without exception review.
- Advanced Imaging Controls — Includes ATW white balance (two modes), fog compensation (0-8 levels), adaptive black stretch, back light and high light compensation (0-31 range), and intelligent auto mode for autonomous operation in variable lighting.
- Flexible Shutter and Maximum Gain Control — Shutter adjustable from 1/10000s to 16/30s (framerate-dependent) with maximum 16/30s exposure for ultra-low-light detail capture; AGC configurable for motion blur vs. sensitivity trade-off.
- AI Processing Relay App Compatibility — Can extend AI-based video analysis to non-AI equipped cameras on the same network, amortizing analytics processing across mixed-generation camera fleets.
i-PRO WV-X22600-V2L Integration & Compatibility
The WV-X22600-V2L supports ONVIF-compliant integration with enterprise video management systems, network-attached storage, and third-party access control platforms. Its network interface operates over standard Ethernet 10Base-T/100Base-TX connectivity. The camera is compatible with i-PRO's AI On-site Learning App for organizations requiring proprietary behavior detection or object recognition. Four independent streams can be individually configured for encoding, resolution, and quality, enabling simultaneous delivery to archival, live monitoring, and mobile clients at optimized bitrates.
