i-PRO WV-U25550-F3L 5MP AI OUTDOOR IR DOME CAMERA

i-PRO WV-U25550-F3L Overview

The i-PRO WV-U25550-F3L is a 5MP outdoor vandal-resistant dome camera engineered for security integrators and IT managers deploying mission-critical surveillance in harsh environments. This U-series camera combines edge-based AI image analytics with robust environmental protection (IP66, IK10 certified) and integrated infrared illumination to deliver 24/7 coverage in low-light and no-light conditions. Built with FIPS 140-3 Level 3 certified SecureElement technology and NDAA compliance, the WV-U25550-F3L meets enterprise security and regulatory requirements across government, critical infrastructure, and sensitive facilities.

i-PRO WV-U25550-F3L Key Features

• 5MP Resolution with 1/2.8" CMOS Sensor: 5.12 mm (H) × 3.84 mm (V) scanning area delivers sharp detail capture for identification and forensic review across wide indoor and outdoor deployment areas.
• Advanced Low-Light Performance: Minimum illumination as low as 0.11 lx (color, 30IRE, F2.0, 1/30s, AGC:11) and 0.004 lx in monochrome with extended shutter, enabling effective surveillance in near-darkness without relying solely on IR.
• Integrated IR LED with 28m Range: Built-in infrared illumination reaches 28 meters (92 ft) at 30IRE, with 20m coverage at 50IRE, providing complete visibility across perimeters and outdoor zones without external lighting infrastructure.
• IP66 and IK10 Certification: Sealed against dust ingress and water jets; rated for impact resistance (IK10 = 20J vandal protection), meeting requirements for exposed outdoor mounting, public spaces, and vandal-prone locations.
• Edge AI Analytics via AI-VMD: On-camera AI-based image analytics with Video Motion Detection (VMD) and Scene Change Detection (SCD) reduce false alarms and processing load on network infrastructure; supports up to one AI application slot for extensible analytics deployment.
• H.265 and H.264 Codec Support: Dual video compression formats (H.265 for bandwidth efficiency, H.264 for broad VMS compatibility) with JPEG still capture, optimizing network throughput and storage capacity for continuous recording.
• 120 dB Dynamic Range with Super Dynamic Mode: Handles extreme lighting contrast (backlit subjects, reflective surfaces, direct sun) through Super Dynamic processing with adjustable levels (0–31) and Adaptive Black Stretch, enabling usable video across mixed day/night scenes.
• FIPS 140-3 Level 3 SecureElement: EdgeLock® SE052F NXP® Semiconductors hardware-based encryption and secure key storage protect sensitive deployments and meet federal cybersecurity compliance mandates.
• NDAA Compliant: Meets U.S. Department of Defense supply chain security requirements, eliminating restrictions on federal and defense contractor procurement.
• Audio Recording Capability: Integrated microphone with AAC-LC (Advanced Audio Coding - Low Complexity) support for correlated audio logging, incident reconstruction, and multi-sensory evidence capture.
• Flexible White Balance and Exposure Control: ATW1, ATW2, and AWC white balance modes; intelligent auto exposure on/off; Fog Compensation (0–8 levels); Back Light Compensation; High Light Compensation; and maximum gain (AGC) settings (0–11) provide operator control across varied environmental and lighting conditions.
• Color/BW Switchable (ICR): Automatic or manual infrared cut filter toggle (IR Light Off, IR Light On, or Auto modes 1–3) optimizes color reproduction in daylight and forces monochrome in IR mode for maximum sensitivity.

i-PRO WV-U25550-F3L Integration & Compatibility

The WV-U25550-F3L is ONVIF-compliant, enabling seamless integration with third-party VMS platforms and standard IP surveillance ecosystems. Audio recording supports AAC-LC codec on SD memory cards, and the camera operates over standard Ethernet network infrastructure. Easy Kitting support simplifies deployment and multi-unit installations. The camera's edge AI processing reduces reliance on centralized analytics servers, allowing integrators to deploy local intelligence at branch sites, remote facilities, or bandwidth-constrained networks while maintaining compliance and forensic video quality.

i-PRO WV-U25550-F3L Package Contents

• i-PRO WV-U25550-F3L camera unit
