i-PRO M-89-F-L Overview
The i-PRO M-89-F-L is an 8MP fixed bullet network camera designed for outdoor surveillance deployments requiring high-resolution 4K video capture and extended infrared range. Built on the Advidia platform, this camera combines a 1/2.7" progressive-scan CMOS sensor with a fixed 4mm lens to deliver forensic-grade image detail across day and night conditions. The M-89-F-L is weatherproof (IP67-rated), field-deployable across -30°C to 60°C temperature ranges, and includes integrated smart analytics and deterrence lighting for perimeter and facility protection.
i-PRO M-89-F-L Key Features
- 4K Ultra HD Video Capture: 3840 x 2160 resolution at 20 fps with progressive-scan CMOS sensor delivers forensic-quality imagery for identification and legal evidentiary use.
- 120dB True WDR (Wide Dynamic Range): Handles extreme lighting contrasts (e.g., backlit scenes, mixed interior/exterior views) without manual adjustment, ensuring usable video in challenging daylight conditions.
- Intelligent Infrared with 30m Range: Dual-mode ICR (infrared cut filter) with automatic day/night switching; Smart IR technology minimizes blooming and extends effective detection to 98 feet (30 meters) in complete darkness.
- Advanced Compression (Ultra 265/H.265/H.264/MJPEG): Multi-codec support enables bandwidth optimization and playback compatibility; H.265 Ultra 265 codec reduces storage footprint by up to 50% versus H.264 at equivalent quality.
- IP67 Weather Sealing & Rugged Construction: Sealed electronics and stainless hardware enable 24/7 outdoor deployment in rain, dust, and salt-spray environments; operating temperature range spans -22°F to 140°F (-30°C to 60°C).
- Integrated Deterrence Light & Audio: Built-in alarm light provides active deterrence on event trigger; integrated microphone and speaker support two-way audio communication and audio-based analytics (detection, tampering alerts).
- Tri-Stream Video & ROI Encoding: Simultaneous multi-bitrate streams (up to 8 ROI areas) enable adaptive bandwidth delivery and reduced network load for resource-constrained deployments.
- Motion & Event Analytics: Cross-line detection, intrusion detection, enter/leave area detection, motion detection, tampering alarms, and audio-triggered events reduce false positives and storage overhead.
- PoE Powered (802.3af) + Local Storage: Maximum 10.5W power draw enables single-run Ethernet deployment; microSD expansion up to 256GB provides redundant edge storage and failsafe recording.
- Comprehensive Network Protocol Support: IPv4, DHCP, DNS, DDNS, NTP, RTSP, SNMP, HTTP/HTTPS, FTP, SSH, SSL/TLS, 802.1X, and QoS enable seamless integration into managed corporate and service provider networks.
- Video Insight VMS Licensing Included: Camera ships with integrated Video Insight license (no per-camera licensing fees); compatible with standard ONVIF-profile surveillance management systems.
- Compact Bullet Formfactor: 91 x 75 x 74mm (3.0" x 2.9" x 7.5") dimensions and 0.41kg (0.90 lbs) weight enable discreet wall and eave mounting without structural reinforcement.
i-PRO M-89-F-L Integration & Compatibility
The M-89-F-L supports standard ONVIF protocols and integrates with Video Insight VMS software (license included); no additional licensing required. Ethernet connectivity via single RJ45 10/100 Base-T interface enables daisy-chain and backbone network architectures. IPv4 multicast and unicast streaming, RTSP playback, SNMP-based health monitoring, and 802.1X authentication ensure compatibility with enterprise network access controls. Optional accessories include the M-JB-MINI-B junction box (M-NPT34 pole mount) for protected cable entry and conduit transitions in challenging outdoor installations.
i-PRO M-89-F-L Package Contents
- i-PRO M-89-F-L Bullet Camera (1x)
- M-JB-MINI-B Junction Box with M-NPT34 Pole Mount (standard accessory)
