i-PRO M-44-V-V3 Overview
The i-PRO M-44-V-V3 is a 4MP (2688x1520) varifocal turret network camera built for reliable indoor and outdoor surveillance deployments. This compact turret combines motorized zoom optics, robust weatherproofing, and integrated IR illumination to deliver day/night coverage in demanding environments where flexibility and durability are essential.
i-PRO M-44-V-V3 Key Features
- 4MP native resolution with motorized 2.8–12mm varifocal lens: Delivers 2688×1520 mainstream video with 4.3× optical zoom range, supporting field-of-view adjustment from 86.3° (wide) to 35.2° (tele) without lens replacement.
- 120 dB WDR and advanced image processing: Forensic-grade wide dynamic range handles extreme backlight and shadow detail simultaneously; Smart IR, HLC (Highlight Compensation), BLC (Backlight Compensation), and digital defog optimize images across varied lighting conditions.
- Integrated IR illumination up to 40 meters (131 ft): 850nm IR LEDs enable full 0 Lux night vision; daytime color minimum illumination rated at 0.003 Lux (F1.6, AGC ON) with >52 dB signal-to-noise ratio.
- H.265, H.264, and MJPEG codec support: Multi-codec flexibility reduces bandwidth and storage demands while maintaining compatibility with legacy and modern VMS platforms; dual stream configuration supports simultaneous high-quality and low-bandwidth transcoding.
- DORI performance across zoom range: Detect to 270m (tele), Observe to 108m (tele), Recognize to 54m (tele), Identify to 27m (tele) — enabling license-plate and facial identification at significantly extended distances compared to fixed-lens alternatives.
- Built-in microphone with G.711U/G.711A audio codec: Enables audio detection analytics and two-way voice capability when integrated with compatible VMS; supports tamper and audio alarm triggers for proactive response.
- IP67 and IK10 certifications: Sealed against dust and water immersion (IP67); impact-resistant to IK10 vandal rating — suitable for outdoor mounting, high-traffic areas, and exposed installation positions.
- PoE (IEEE 802.3af) powered: Maximum 7.5W consumption supports standard PoE injection without additional power supplies; also accepts DC 12V ±25% input via 5.5mm coaxial jack for flexible power architecture.
- Advanced analytics including human body detection: Motion detection, cross-line intrusion, tampering alarm, and ROI (Region of Interest) configuration across 8 discrete areas ensure focused alerting and reduced false alarms.
- Motorized pan/tilt/rotate adjustment: Pan 0–360°, tilt 0–75°, rotation 0–360° for precise aiming without remounting; image flip, rotation, and 180° flip support diverse mounting orientations.
- Comprehensive security and compliance: TLS 1.2, HTTPS, WSSE authentication, IP address filtering, ARP protection, MAC filtering, and illegal login lockout protect against unauthorized access; NDAA compliance and UL/FCC/CE certifications address federal and regional deployment requirements.
- microSD card slot (up to 256 GB): Local edge storage option for footage backup and forensic retention independent of network recorder availability.
i-PRO M-44-V-V3 Integration & Compatibility
The M-44-V-V3 supports ONVIF Profile S, G, and T, ensuring interoperability with ONVIF-compliant VMS platforms and third-party management software. Standard network protocols include IPv4, DHCP, DNS, DDNS, NTP, RTSP, RTMP, HTTP, HTTPS, SNMP, and 802.1X authentication for enterprise network integration. Built-in microSD storage enables local recording and edge analytics when centralized NVR architecture is unavailable. Compact turret form factor (Ø129 × 110 mm) fits standard wall and ceiling mounts; 360° rotation capability accommodates angled installations without optical distortion.
