HES PDB-8F2 Power Distribution Unit 8 Fused Output

HES PDB-8F2 Power Distribution Unit 8 Fused Output

The HES PDB-8F2 is a dedicated power distribution unit engineered for security and access control systems requiring reliable, protected power delivery across multiple circuits. Designed for professional integration into rack-mounted and wall-mounted security installations, this unit centralizes power management while providing individual fuse protection on each output, ensuring circuit isolation and redundant overcurrent safeguards.

Key Features

• 8 independently fused outputs for isolated circuit protection
• Compatible with HES and third-party security control panels
• Supports fire alarm system integration
• 19-inch rack mount and wall-mount form factors
• Individual fuse protection on all circuits
• Centralized power management for networked security devices

Technical Highlights

The PDB-8F2 distributes power from a single input across eight separate outputs, each protected by its own fuse. This architecture eliminates the risk of a single component failure cascading across your entire security infrastructure. The unit accommodates both standard rack installations and wall-mounted configurations, making it suitable for diverse deployment scenarios from small-scale access control systems to larger networked security environments.

The modular fused output design allows for granular power management across access control readers, door locks, surveillance equipment, alarm sensors, and networked security devices. Each output operates independently, meaning a fault or overcurrent condition on one circuit will not affect the remaining seven outputs.

Applications

• Networked access control systems and card readers
• Surveillance camera and NVR power distribution
• Fire alarm system auxiliary power
• Security panel remote power expansion
• Multi-device security infrastructure consolidation

Package Contents

• Power Distribution Module with 8 Fused Outputs
• Fuses
• Mounting Hardware
