Features:
IR
Frame Rate:
Variable
Active Pixels:
3840 (H) x 2160 (V)
Sensor Type:
4K 1/2.8" CMOS sensor
Maximum resolution:
4K
Minimum Scene Illumination in color:
0.0 lux (B/W), 0.09 lux (color)
Test Video Output:
Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels:
3864(H) x 2228(V)
Advanced Lens Features:
Auto focus, Motorized zoom, P-iris
Focal Length:
2.7mm ~ 13.5mm
Horizontal Field of View (HFOV:
90.3° ~ 33.1°
IR Distance:
100' range Smart IR™
Lens Type:
Vari-focal Lens
Vertical Field of View (VFOV:
18.9°~49
Audio compression:
G.711
I/O Alarm in/out:
1 input, 1 output
I/O Audio in/out:
*Cameras provide a line level audio. The use of amplified microphones and speakers is recommended., 1 input, 1 output
IVA license:
Intrusion, line crossing, counting line, loitering, enter, exit, tamper
IVA+ license:
Logical rules, object removed, tailgating, direction, stopped, appear, disappear, object left
3D digital noise reduction:
Smart DNR™ 3D Digital Noise Reduction
Auto gain control:
Auto
Backlight compensation (BLC:
Yes
Day and Night:
Auto day/night, Day (color), Night (B/W)
De-fog:
Yes
Memory slot:
Micro SD/SDHC/SDXC class 10 card (card not included), Up to 1TB micro SD / FAT32
Mirror/flip:
Yes
Motion Detection:
Yes
Operational Notifications:
Alarm output activation, Email, FTP server, SD card recording
Privacy Zones:
16 programmable privacy masks
Sharpness:
Yes
Shutter Mode:
Anti-Flicker, Auto, Manual, Slow Shutter
Shutter Speed:
1/15 ~ 1/32000
Slow Shutter Speed:
Off, x10, x2, x3, x5, x6, x7.5
White Balance:
Yes
Wide Dynamic Range (WDR:
True WDR 120dB
Bitrate Control:
Multi-streaming CBR/VBR at H.264, H.265 (controllable frame rate and bandwidth)
IP:
IPv4
LAN:
1000Base-T (1Gbps)
Network resolution:
H.264: QFHD, 2.1MP/1080p, 720p, VGA, D1, CIF, H.265: QFHD, 2.1MP/1080p, 720p, VGA, D1, CIF, MJPEG: 2.1MP/1080p, 720p, 800x600, VGA, 768x432, D1, CIF
Network Web Viewer:
Google Chrome® browser, Linux® OS, Mac® OS, Microsoft Edge® browser, Mozilla Firefox® browser, Safari® browser, Windows® OS
Protocol:
DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP)
Security:
802.1x, Digest authemtication (ID/PW), HTTPS (TLS), IP filtering
Stream Speed:
Up to 30fps at all resolutions
Streaming Capability:
Dual-stream at different rates and resolutions
Video Bitrate:
100Kbps~10Mbps, multi-rate for preview and recording
Video Compression Type:
H.264, H.265, MJPEG
Video Management Software:
Any ONVIF conformant CMS, DW Spectrum® IPVMS, ExacqVision Technologies, Genetec Inc., Milestone Systems
Environmental Operating Humidity:
10-90% (non-condensing)
Environmental Operating Temperature:
-4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional:
Optional. Sold separately
Camera Dimensions (H X W X D:
4.92" x 4.4" (125 x 112mm)
Camera Weight:
1.87 lbs (0.85kg)
Housing:
Vandal ball turret, Turret
Housing Color:
White
IK rating:
IK09 Rated
IP Rating:
IP66
Materials:
Aluminum die-casting, Galaxy™ Housing
American wire gauge (AWG:
Cable type #18
Power Consumption:
DC12V: 12.4W, 1033mA, PoE: 14.9W
Power Requirements:
Adapter not included, PoE
Warranty:
5 Year Warranty
Product Type:
Turret
Connectivity:
Wired
Power Type:
PoE
Resolution:
8MP
Night Vision:
IR
