Hanwha HV-X530DP-28GHXM-900 20 x Gigabit Ethernet 4x1/2.5/5

Hanwha HV-X530DP-28GHXM-900 Overview

The Hanwha HV-X530DP-28GHXM-900 is a 28-port managed Ethernet switch purpose-built to power and manage large-scale network camera installations. This model combines 20 Gigabit Ethernet ports with 4 variable-speed ports (1/2.5/5 Gbps PoE++) and 4 dedicated 10GB SFP+ uplink ports, delivering 1480W of PoE++ power capacity to support 24 PoE++-sourcing ports simultaneously. Optimized specifically for Hanwha network camera deployments, this switch provides enterprise-grade switching fabric and redundant power for mission-critical surveillance infrastructure.

Hanwha HV-X530DP-28GHXM-900 Key Features

• 28-Port Architecture: 20x 10/100/1000 Mbps Gigabit Ethernet copper ports plus 4x 1/2.5/5 Gbps variable-speed PoE++ ports, enabling flexible port speed allocation based on camera power and bandwidth requirements
• 1480W PoE++ Power Budget: Full PoE++ (802.3bt Class 4, 60W per port) on all 24 PoE-sourcing ports, supporting simultaneous deployment of high-power PTZ, multi-sensor, and 5 MP+ fixed cameras without central power supply concerns
• 4x 10GB SFP+ Uplinks: 160 Gbps switching fabric with 119 Mpps forwarding rate ensures non-blocking performance even under heavy concurrent PoE draw; SFP+ ports enable aggregated backhaul to NVR infrastructure or data center core switches
• Dual Hotswap PSU Bays: Accepts two HV-PWR1200V2-10 power supplies (sold separately) for N+1 redundancy; supports automatic failover to maintain PoE delivery during single supply failure, critical for unattended outdoor installations
• Advanced Managed Features: Enterprise-grade switching with support for VLAN, QoS, port mirroring, and link aggregation (LACP) for sophisticated network segmentation and traffic engineering in large multi-building surveillance systems
• Low Latency Switching: Latency as low as 1.63µs at 10 Gbps and 4.05µs at 1 Gbps ensures real-time camera stream delivery without buffering, critical for live monitoring and multi-camera correlation
• Compact 1RU Form Factor: 441mm (17.36 in) width and 44mm (1.73 in) height fit standard 19-inch rack environments with minimal footprint, supporting dense deployments in communication closets and equipment rooms
• Thermal Management: Operating specifications at full PoE++ load with dual PSU configuration ensure reliable operation in controlled indoor environments; 6279 BTU/h maximum heat dissipation with manageable 63 dBA noise profile
• Hanwha Camera Optimization: Firmware and power delivery engineered specifically for Hanwha network camera product line, ensuring compatibility with proprietary features such as auto-sensing and seamless integration with Hanwha NVR and VMS platforms

Hanwha HV-X530DP-28GHXM-900 Integration and Compatibility

As a managed Ethernet switch, this device operates at OSI Layer 2/3 and is compatible with standard ONVIF-compliant IP cameras from any manufacturer, though it is optimized for Hanwha camera deployments. The dual SFP+ uplink ports support standard fiber or copper DAC connections to NVR systems, video analytics servers, or aggregation switches. Advanced managed features including VLAN, QoS per-port queuing, and LACP link aggregation enable integration into complex security network architectures with enterprise video management systems (VMS) supporting standard Ethernet protocols.

Hanwha HV-X530DP-28GHXM-900 Package Contents

• HV-X530DP-28GHXM-900 switch unit (20-port 10/100/1000T + 4-port 1/2.5/5G PoE++ stackable switch with 4 SFP+ ports and dual hotswap PSU bays)
• Rack-mount brackets and screws
• Rubber feet
• Power cord
• HV-PWR1200V2-10 1200W system and PoE power supply (compatible unit sold separately)
