Hanwha HV-X250-18XS-10 10 Gigabit Layer 3 Stackable Switch

Hanwha HV-X250-18XS-10 Overview

The Hanwha HV-X250-18XS-10 is a 10 Gigabit Layer 3 Lite stackable switch purpose-built for IP surveillance and network camera infrastructure. This low-to-mid-range top-of-rack (TOR) switch delivers enterprise-grade switching performance optimized specifically for Hanwha network camera products and compatible with Allied Telesis switching ecosystem. Designed for deployments requiring high-density 10 Gigabit connectivity across fiber-based camera networks, the HV-X250-18XS-10 reduces bottlenecks in video transport and supports scalable, reliable surveillance architectures.

Hanwha HV-X250-18XS-10 Key Features

• 18x SFP/SFP+ Ports: Eighteen 10 Gigabit SFP+ fiber ports deliver high-capacity uplink and inter-switch connectivity for large-scale surveillance deployments without copper bandwidth constraints.
• 10 Gigabit Layer 3 Lite Architecture: Provides wire-speed Layer 3 routing capability with simplified management overhead, eliminating the complexity and cost of full-featured core switches while maintaining network intelligence for VLAN segmentation, QoS, and traffic prioritization.
• Stackable Design: Multiple units can be stacked for simplified management and scaled redundancy, reducing operational overhead in multi-switch deployments and enabling unified configuration across the switching fabric.
• Allied Telesis AlliedWare Plus Operating System: Industry-standard command-line interface (CLI) and graphical management interface enable remote configuration and monitoring via SSH, serial console, and web-based GUI. Factory-unconfigured units receive automatic IPv4 and IPv6 management addresses on startup, enabling zero-touch initial deployment.
• Single Fixed PSU with US Power Cord: Integrated power supply with standard US connector eliminates separate power modules and simplifies installation in North American surveillance facilities.
• Optimized for Hanwha Network Cameras: Tested and validated interoperability with Hanwha Vision network cameras, ensuring seamless integration into surveillance systems and optimized performance for real-time video streaming and storage.
• Automatic Address Assignment: From software version 5.4.7-0.4 onwards, factory-new devices automatically assign IPv4 and IPv6 addresses to the management interface, reducing initial configuration time and enabling immediate remote SSH access.
• Flexible Management Interface: Management accessible via Ethernet-based interface (eth0 or NET MGMT port), vlan1, or first link-up port; supports both serial console (baud rates up to 115200) and network management protocols.

Hanwha HV-X250-18XS-10 Integration & Compatibility

The HV-X250-18XS-10 operates on Allied Telesis AlliedWare Plus, a widely deployed network operating system with extensive documentation, training guides, and community support. Compatible with standard SNMP monitoring, syslog, and CLI management workflows common in surveillance and enterprise IT environments. Stackable architecture supports unified management of multiple switches through AlliedWare Plus VSS (Virtual Switching System) files and configuration export/import. Integrates with existing Hanwha Vision camera deployments and compatible with third-party ONVIF-compliant surveillance systems via standard Layer 3 routing and VLAN support. Supports remote management via SSH and web GUI for centralized network administration across distributed camera sites.
