Hanwha QNV-C8083R/KDO Outdoor Vandal Dome Camera

Hanwha QNV-C8083R/KDO Overview

The Hanwha QNV-C8083R/KDO is a 5MP outdoor vandal-resistant dome camera engineered for demanding surveillance deployments requiring high-resolution capture, intelligent video analytics, and extreme weather durability. This model combines motorized varifocal optics with AI-powered analytics and triple codec support, making it suitable for campus perimeters, commercial properties, and critical infrastructure monitoring.

Hanwha QNV-C8083R/KDO Key Features

• 5MP resolution at 30 fps — Delivers sharp detail across standard IP network infrastructure without bandwidth bottlenecks; triple codec support (H.265, H.264, MJPEG) ensures compatibility with legacy and modern VMS platforms.
• Motorized varifocal lens (3.2–10.2mm) — Horizontal field of view ranges 95° (wide) to 29° (telephoto); vertical field 69° to 21°. Enables precise framing adjustments during installation without lens swap or physical repositioning.
• 120dB Wide Dynamic Range (WDR) — Captures detail in extreme lighting transitions (bright sunlit areas adjacent to deep shadows) without image washout or underexposure.
• 30-meter IR illumination (98 feet) — Integrated IR LEDs provide reliable night vision in complete darkness; IR viewable length supports mid-range perimeter coverage and parking lot surveillance.
• AI-powered video analytics — Wisenet AI engine detects and classifies objects in real time: Person and Vehicle detection with vehicle subtype recognition (car, bus, truck, motorcycle, bicycle). Virtual line crossing and direction detection; virtual area loitering, intrusion, entry/exit, and appearance/disappearance analytics. Defocus detection alerts to lens obstruction or alignment drift.
• WiseStream III adaptive bitrate compression — AI-driven bitrate optimization reduces storage and bandwidth without sacrificing image quality; WiseNR AI-based noise reduction maintains clarity in low-light conditions.
• IP66 weatherproofing and IK10 vandal resistance — Sealed against dust, water jets, and moisture ingress; impact-rated to withstand IK10 strikes (20J equivalent), protecting against hammer blows and intentional damage in accessible outdoor locations.
• Extended operating temperature range — Functions reliably from –30°C to +55°C (–22°F to +131°F), suitable for extreme climates without auxiliary heating or cooling.
• PoE power (802.3af) — Single Ethernet cable delivers power and bidirectional data; simplifies installation and eliminates separate AC line runs.
• Audio and alarm support — Built-in microphone input and line-level audio input (selectable); alarm I/O and audio connectivity via optional SPP-C7400 audio/alarm cable (sold separately). Hallway View mode optimizes image composition for vertical corridor coverage.
• Local storage and open platform — microSD card slot supports offline recording and failover; ONVIF-compliant open platform architecture ensures integration with third-party VMS and NVR systems without vendor lock-in.

Hanwha QNV-C8083R/KDO Integration & Compatibility

The QNV-C8083R/KDO adheres to ONVIF Profile S standards, enabling seamless integration with ONVIF-compatible VMS platforms, NVRs, and video management software. PoE power delivery via 802.3af simplifies network deployment; USB port supports easy firmware updates and configuration. The camera operates as an open platform device, allowing integration into multi-vendor surveillance architectures without proprietary controller dependencies. Varifocal lens control and analytics tuning are accessible via standard ONVIF interfaces or manufacturer configuration tools.

Hanwha QNV-C8083R/KDO Package Contents

• QNV-C8083R/KDO camera unit (white finish)
• Mounting hardware and installation documentation
• Audio and alarm connectivity requires optional SPP-C7400 cable (3-pack, 700mm coil)
