Hanwha QNV-6082R1/KME Outdoor Vandal Dome Camera

Hanwha QNV-6082R1/KME Overview

The Hanwha QNV-6082R1/KME is a 2MP outdoor vandal-resistant dome camera designed for secure perimeter and facility monitoring. Built for harsh environmental conditions with IP66 ingress protection and IK10 vandal rating, this camera delivers reliable surveillance across a wide field of view with motorized zoom control and advanced low-light performance. The model combines triple codec support with intelligent compression to optimize bandwidth and storage without sacrificing image quality.

Hanwha QNV-6082R1/KME Key Features

• 2MP Resolution at 30fps — Captures clear, detailed video suitable for wide-area outdoor surveillance and forensic review across multiple codec options.
• Motorized Varifocal Lens (3.1x zoom, 3.2–10.0mm) — Provides 109° wide field of view down to 33° telephoto, allowing remote focal length adjustment for deployment flexibility without camera repositioning.
• Triple Codec Compression (H.265/H.264/MJPEG) with Wisestream II — Reduces bandwidth and storage consumption while maintaining video fidelity; supports legacy H.264 and MJPEG for broad VMS compatibility.
• 120dB Wide Dynamic Range — Delivers balanced exposure in mixed lighting, from bright daylight to shadowed areas, enabling 24/7 monitoring across uneven illumination.
• IR LED Array with 98ft Range — Extends night vision capability for continuous surveillance when ambient light is unavailable or insufficient.
• IP66 Weatherproofing and IK10 Vandal Rating — Withstands dust, water spray, and physical impact, meeting standards for outdoor exposed and high-risk deployment environments.
• Defocus Detection and Hallway View — Alerts on lens obstruction and supports corridor-mode aspect ratios for vertical mounting applications.
• Video Analytics — Enables motion detection, object tracking, and event-driven alerting at the edge, reducing false positives and NVR processing load.
• SD Card Local Storage — Provides backup recording and edge-based retention independent of network connectivity.
• CVBS Output — Supports analog fallback for integration with legacy DVR systems or direct monitoring.
• PoE (802.3af) or 12VDC Power — Flexible power delivery; PoE simplifies installation on managed network infrastructure while 12VDC option supports standalone or non-PoE deployments.
• Open Platform Architecture — ONVIF-compliant for vendor-neutral VMS integration, API access, and third-party application development.

Hanwha QNV-6082R1/KME Integration & Compatibility

The QNV-6082R1/KME supports ONVIF Profile S standard, enabling seamless integration with Milestone XProtect, Genetec Security Center, March Networks, and other enterprise VMS platforms. CVBS analog output allows fallback monitoring on DVR systems or analog displays. Video analytics are processed on-device, reducing bandwidth to the recording server and supporting real-time event triggering via ONVIF events or vendor-specific webhooks. The motorized lens is controlled via ONVIF PTZ commands, allowing remote focus and zoom adjustment from compatible client software.
