Hanwha PNM-C16083RVQ RB Rebox: P series network vandal outdoor

Hanwha PNM-C16083RVQ RB Overview

The Hanwha PNM-C16083RVQ RB is a 4-channel multi-directional network camera engineered for outdoor surveillance in demanding environments. This rebox form factor combines four 4MP sensors into a single device, reducing installation complexity and infrastructure cost while delivering comprehensive coverage with one network cable and IP address.

Hanwha PNM-C16083RVQ RB Performance & Imaging

• 4MP per sensor at 30 fps full resolution
• Motorized varifocal lens 3.3–5.7mm with horizontal FoV 100°, vertical FoV 54°
• 120dB Wide Dynamic Range for high-contrast outdoor scenes
• 20m (65.6 ft) infrared illumination for 24/7 visibility
• Triple codec support: H.265, H.264, MJPEG for flexible bandwidth and storage optimization

Hanwha PNM-C16083RVQ RB Durability & Installation

• IP66 weatherproofing and IK10 vandal rating for outdoor/exposed deployments
• NEMA 4X stainless steel housing
• PoE+ (802.3at) powered—single cable simplifies wiring
• USB port for rapid on-site setup and configuration

Hanwha PNM-C16083RVQ RB Analytics & Intelligence

• AI-driven object detection: Person, vehicle (car/truck/bus), bicycle, motorcycle
• Intelligent Video Analytics (IVA): virtual line/area crossing, enter/exit, loitering, direction, intrusion detection
• Appear/Disappear event triggers
• WiseNR AI-based noise reduction
• WiseStream bandwidth optimization powered by AI engine

Hanwha PNM-C16083RVQ RB Security & Compliance

• TPM with FIPS 140-2 Level 2 cryptographic module
• I/O Box compatibility for flexible integration
