Hanwha XND-A9084RV/KEX Powered by WN9

Hanwha XND-A9084RV/KEX Overview

The Hanwha XND-A9084RV/KEX is an 8MP indoor network dome camera powered by the WN9 AI engine, engineered for surveillance applications requiring advanced object detection, intelligent video analytics, and reliable day/night performance. Designed for installation in controlled indoor environments, this camera combines high-resolution imaging with AI-driven intelligence to deliver actionable security intelligence without external infrastructure overhead.

Hanwha XND-A9084RV/KEX Key Features

• 8MP Resolution at 30 FPS — Captures detailed forensic-quality imagery at full 8MP resolution with 30 fps frame rate, supporting H.265, H.264, and MJPEG codecs for flexible bandwidth and storage optimization.
• WN9 AI Engine with Dual NPU — Embedded AI processing delivers real-time object classification (Person, Face, Vehicle, License Plate) and attribute recognition (gender, clothing color, age, vehicle type/color) directly on the camera without cloud dependency.
• Motorized Varifocal Lens 4.4–9.3mm (2.1x Zoom) — Adjustable 113° to 47° field of view via motorized varifocal control, enabling flexible scene coverage and subject framing post-installation.
• Infrared Night Vision — 40m Range — 40-meter (131.2 ft) IR illumination with Day/Night (ICR) switching provides round-the-clock visibility in low-light and no-light conditions; hard-coated dome bubble protects IR performance and resists scratching.
• 120dB Extreme Wide Dynamic Range (extremeWDR) — Handles extreme lighting contrasts (backlit scenes, mixed indoor/outdoor views) while maintaining detail in both bright and dark areas simultaneously.
• AI-Based Analytics Engine — Intelligent Video Analysis (IVA) includes motion detection, object detection, line crossing, area intrusion, slip & fall detection, and sound classification. Business intelligence features add people counting, vehicle counting, crowd detection, queue management, and heatmap generation.
• WiseStream and WiseNR Technology — AI-optimized bitrate management (WiseStream) reduces bandwidth and storage without sacrificing quality; WiseNR applies neural-network-based noise reduction for cleaner video in low-light scenarios.
• Digital Image Stabilization (DIS) with Built-in Gyro — Compensates for camera shake and vibration, critical for installations on vibrating structures or in areas prone to movement.
• PoE Powered (802.3af, Class 3) — Single Cat5e/Cat6 connection delivers power (max 11.2W, typical 8.4W) and data; metal-shielded RJ-45 port ensures electromagnetic immunity in noisy industrial and commercial environments.
• Edge Storage up to 1TB — Integrated microSD/SDHC/SDxC slot (maximum 1TB) enables local backup and continuous recording without NVR dependency; supports Hanwha Vision-certified cards for guaranteed reliability.
• Rugged IP52/IK10 Construction — IP52 rating protects against dust and water spray; IK10 impact resistance (20 joules) withstands deliberate and accidental vandalism, suitable for high-traffic and hostile environments.
• Extended Operating Temperature -10°C to +50°C — Operates reliably in heated indoor spaces and uncontrolled environments; humidity control via integrated AIRvent prevents lens fogging.
• Advanced Privacy & Security Features — Dynamic privacy mask obfuscation; BestShot function selects optimal frames for forensic clarity; Handover capability for smooth handoff between recording systems; defocus, tampering, and fog detection analytics.

Hanwha XND-A9084RV/KEX Integration & Compatibility

The XND-A9084RV/KEX supports ONVIF-based integration with standard VMS platforms and ONVIF-compliant third-party systems. The camera operates on PoE (IEEE 802.3af, Class 3), compatible with standard PoE injectors and switches. Integration with Hanwha Vision CloudConnector (WN9 v2.1.6 or later) enables cloud connectivity and centralized management. Mounting options include single-gang, double-gang, 4-inch octagon, and square electrical boxes via the 12.7mm (1/2") M20 conduit hole. The Wisenet9 architecture supports firmware updates for ongoing feature enhancement and security patches.

Hanwha XND-A9084RV/KEX Technical Specifications

• SoC: Wisenet9 with Dual NPU
• Memory: 4GB RAM, 8GB eMMC Flash
• Video Resolution: 8MP (3840 × 2160)
• Frame Rate: 30 fps
• Lens: 4.4–9.3mm motorized varifocal (F1.8–F2.7)
• Field of View: 113° (wide) to 47° (tele)
• Zoom Ratio: 2.1×
• IR Range: 40m (131.2 ft)
• Day/Night: Automatic ICR switching
• WDR: extremeWDR 120dB
• Video Codecs: H.265, H.264, MJPEG
• Edge Storage: microSD/SDHC/SDxC up to 1TB
• Power: PoE (IEEE 802.3af, Class 3); Max 11.2W, Typical 8.4W
• IP Rating: IP52
• IK Rating: IK10
• Operating Temperature: -10°C to +50°C (+14°F to +122°F)
• Humidity: 0–100% RH (condensing) with AIRvent humidity control
• Physical Dimensions: ø160 × 118mm (6.30 × 4.65 inches)
• Weight: 1,020g (2.25 lbs)
• Color: White (RAL 9003)
• Material: Aluminum, Polycarbonate, hard-coated dome bubble
• Mounting: Single, double, 4-inch octagon, square electrical boxes (M20/12.7mm conduit hole)
• Network Port
