Hanwha HV-IE220-10GHX-K90 Industrial rugged switch with 8 x

Hanwha HV-IE220-10GHX-K90 Overview

The Hanwha HV-IE220-10GHX-K90 is an industrial-grade managed Ethernet switch designed for rugged network infrastructure supporting high-density PoE camera deployments. This DIN rail-mountable switch delivers 8 × 10/100/1000Base-T copper ports with full PoE++ (802.3bt) support and optional dual 1G/10G SFP+ uplink ports, providing 240W total PoE power budget. Purpose-built for Hanwha network camera ecosystems, the HV-IE220-10GHX-K90 operates in industrial environments where reliability, compact form factor, and federal compliance are non-negotiable.

Hanwha HV-IE220-10GHX-K90 Key Features

• 8 × Gigabit Ethernet PoE++ Ports: All 8 copper ports support IEEE 802.3bt PoE++ with up to 90W per port (when powered properly) and a shared 240W total PoE power budget, enabling deployment of power-hungry PTZ cameras and multi-sensor systems without additional midspan injectors.
• Dual 10G SFP+ Uplink Ports: Two 1G/10G SFP+ ports provide high-speed uplink connectivity for backbone aggregation, Gigabit ring redundancy, or 10GbE fiber interconnect to core network infrastructure without bandwidth bottlenecking.
• 56 Gbps Switching Fabric & 41.7 Mpps Forwarding Rate: Layer 2+ switching performance with ultra-low latency (2.78 µs at 1Gbps, 2.33 µs at 10Gbps) ensures deterministic packet delivery critical for real-time video surveillance and redundancy protocols.
• DIN Rail or Wall Mount Configuration: Compact 65 × 137 × 155 mm aluminum enclosure (1.60 kg) with flexible mounting options—DIN rail for control cabinets or wall-mount for field installations, IP30-rated metal shell for indoor industrial deployment.
• Fanless Design with Passive Thermal Management: No moving parts reduces operational noise (quiet operation) and eliminates maintenance burden in 24/7 surveillance operations; maximum power consumption 266W with non-PoE load, dissipating up to 87.7 Btu/h.
• NDAA and TAA Compliant: Meets U.S. federal procurement requirements, enabling deployment in government, critical infrastructure, and defense-contractor surveillance networks without compliance risk.
• Wide Input Voltage Range (37–57V DC): Accepts power from standard industrial AC/DC supplies (HV-IE048-240-20 or HV-IE048-480-20 sold separately), accommodating legacy and modern power distribution architectures.
• Industrial-Grade Reliability: Aluminum construction with sheet metal casing, IP30 protection rating, and fanless design ensure long-term operation in temperature-variable indoor environments without condensation or dust ingress concerns.
• PoE++ Class Support Across All Protocols: Full support for IEEE 802.3at (PoE), IEEE 802.3at Type 2 (PoE+), IEEE 802.3bt Type 3 (PoE++), and IEEE 802.3bt Type 4 (PoE++) requires 54V DC sourcing, enabling maximum power delivery to Class 4 devices (95W+).
• Ring Redundancy & Layer 2+ Management: Layer 2+ switching stack supports rapid spanning tree protocol (RSTP) and other managed features for self-healing network topologies and redundant camera path failover in mission-critical installations.

Hanwha HV-IE220-10GHX-K90 Integration & Compatibility

The HV-IE220-10GHX-K90 is optimized for integration with Hanwha network camera product lines and supports standard ONVIF-compliant IP cameras from multivendor ecosystems. As a Layer 2+ managed switch, it operates transparently with industry-standard VMS platforms (Milestone Xprotect, Axis Camera Station, and others) and supports standard Ethernet-based camera discovery and provisioning via DHCP, static IP, or SNMP-based management tools. The dual SFP+ uplinks provide fiber-optic interconnect options for long-distance backbone runs or integration with enterprise network core infrastructure. No special drivers or APIs are required; the switch operates as a transparent managed Ethernet bridge compatible with any ONVIF Profile S-compliant camera and NVR ecosystem.
