Hanwha HV-IE220-6GHX-K90 Overview

The Hanwha HV-IE220-6GHX-K90 is a 4-port industrial rugged Ethernet switch designed for mission-critical network infrastructure in surveillance and industrial deployments. Optimized for integration with Hanwha network camera products, this fanless Layer 2+ managed switch delivers 180W of PoE++ (802.3bt) power budget across four Gigabit ports, with optional scalability through dual 1G/10G SFP+ uplink ports. Built for harsh environments with DIN rail mounting, aluminum construction, and IP30 enclosure protection, it provides the reliable network backbone required by security integrators, telecom operators, and IT infrastructure teams.

Hanwha HV-IE220-6GHX-K90 Key Features

• PoE++ (802.3bt) Power Delivery: 180W total PoE budget across 4 PoE-enabled Gigabit copper ports, supporting high-power network cameras and field devices without separate injectors. Requires 54V DC input to enable full PoE++ and PoE+ operation.
• 4x Gigabit Ethernet Copper Ports: 10/100/1000 Mbps auto-sensing ports with low latency (2.81µs @ 1 Gbps) for real-time video and data transmission across surveillance networks.
• Scalable Uplink Capacity: 2x 1G/10G SFP+ uplink ports (optical fiber or copper DAC capable) enable expansion to 10 Gigabit backbone speeds without copper port constraints, supporting high-bandwidth core aggregation and multi-camera clusters.
• Industrial-Grade Fanless Design: Passive cooling eliminates mechanical failure points and acoustic noise, essential for 24/7 unattended deployments in sensitive environments. Sealed aluminum construction with IP30 rating protects against dust and environmental contaminants.
• DIN Rail Mount Form Factor: Compact dimensions (2.56 x 5.39 x 6.12 inches; 1.57 kg) enable seamless integration into standard equipment racks, electrical cabinets, and vehicle-mount systems. Wall-mount option (1.45 kg) also available for flexible deployment topologies.
• High Switching Fabric & Forwarding Performance: 48 Gbps switching fabric with 35.7 Mpps (million packets per second) forwarding rate ensures non-blocking throughput for multi-stream 4K camera feeds and simultaneous network traffic without congestion or frame loss.
• Layer 2+ Managed Switching: Supports VLAN tagging, QoS, and traffic prioritization for optimized video stream handling and network segmentation across distributed camera installations.
• NDAA and TAA Compliance: Meets U.S. government cybersecurity supply chain requirements, qualifying for federal and defense-sector deployments with strict sourcing and integrity standards.
• Wide Input Voltage Range: 37–57V DC operating range accommodates both standard and industrial power supplies (HV-IE048-240-20 or HV-IE048-480-20 sold separately), enabling flexible power architecture and redundancy configurations.
• Ultra-Low Latency: Microsecond-level latency (12.02µs @ 100 Mbps; 2.31µs @ 10 Gbps) critical for time-sensitive surveillance metadata, synchronized recording, and real-time analytics pipelines.
• Aluminum & Metal Enclosure: Rugged construction rated for industrial operating environments with passive thermal management and EMI shielding suitable for outdoor cabinets, utility installations, and temperature-fluctuating locations.

Hanwha HV-IE220-6GHX-K90 Integration & Compatibility

The HV-IE220-6GHX-K90 is engineered as a Layer 2+ managed switch and integrates with standard industrial Ethernet ecosystems and Hanwha Vision surveillance platforms. Copper ports support standard ONVIF-compliant network cameras from any manufacturer, while SFP+ uplink ports enable fiber optic backbone connections for extended distance runs and electromagnetic immunity. The switch operates as a standalone managed device requiring external power supply (HV-IE048-240-20 at 240W or HV-IE048-480-20 at 480W recommended for full PoE++ budget; HV-IE048-120-20 120W option also available). Installation requires DIN rail infrastructure or wall-mount bracket provisioning in surveillance vaults, telecom huts, or industrial control enclosures.
