i-PRO M-46-FW-V3 Overview
The i-PRO M-46-FW-V3 is a 4-megapixel fixed indoor/outdoor dome camera engineered for demanding surveillance deployments where vandal resistance and infrared night vision are essential. Built on Advidia technology, this compact dome combines True WDR (120dB), H.265 codec efficiency, and 30-meter IR illumination in a form factor rated IP67 and IK10, making it suitable for exposed outdoor locations, doorways, and high-traffic areas where environmental durability and impact resistance are non-negotiable. NDAA compliance qualifies this unit for federal procurement and sensitive installations.
i-PRO M-46-FW-V3 Key Features
- 4 Megapixel Resolution with Progressive Scan CMOS Sensor — Captures 2688 × 1520 native resolution at 25 fps, based on a 1/2.7" 5.0 MP progressive scan CMOS sensor, delivering clear detail across outdoor and indoor scenes without interlace artifacts.
- True Wide Dynamic Range (120dB) — Handles extreme lighting contrasts—bright sunlit areas adjacent to deep shadows—without loss of detail in either zone, critical for entrance monitoring and mixed-lighting environments.
- Dual-Codec Video Compression (H.265, H.264, MJPEG) — Supports H.265 (HEVC) for bandwidth and storage efficiency, H.264 for broad VMS compatibility, and MJPEG for motion-optimized scenarios; bitrate range 128 Kbps to 6144 Kbps allows fine-tuned streaming and recording across network conditions.
- 30-Meter Infrared Range with Auto Day/Night ICR — Equipped with auto-switching IR-cut filter and up to 30m (98.4 ft) infrared illumination for round-the-clock monochrome surveillance; minimum color illumination of 0.003 lux at F1.6 with AGC, extending usable dusk/dawn observation.
- 2.8mm Fixed Lens with 110° Horizontal Field of View — Fixed 2.8mm@F1.6 lens with 110° H × 58.7° V angle of view (130° diagonal) optimized for mid-range coverage zones; F1.6 aperture maximizes available light in low-lux scenarios.
- DORI (Detection, Observation, Recognition, Identify) Performance — Achieves detection at 63 meters (206.7 ft), observation at 25.2 meters (82.7 ft), recognition at 12.6 meters (41.3 ft), and identification at 6.3 meters (20.7 ft) with the 2.8mm lens, defining practical surveillance distances for operational planning.
- IP67 Weatherproof and IK10 Vandal-Resistant Enclosure — IP67 rating ensures full dust ingress protection and immersion in water up to 1 meter, while IK10 impact rating withstands 20 joules of concentrated force, suitable for exposed outdoor mounting and high-contact areas.
- Embedded Analytics with Human-Body Detection — Intrusion detection and cross-line detection algorithms tuned to human body shapes reduce false alarms; includes motion detection, ultra motion detection, tampering alarm, and audio detection for comprehensive event classification.
- 8-Area ROI (Region of Interest) Codec Support — Define up to 8 independent regions for selective codec application, allowing high-quality encoding in priority zones (entrance, cash register) while reducing bitrate in static backgrounds.
- Built-in Microphone and Audio Compression — Integrated audio input with G.711U and G.711A compression enables two-way voice communication and event audio logging without external interface modules.
- microSD Edge Storage up to 512GB — On-camera local recording via microSD slot (up to 512GB capacity) provides offline backup and failover recording independent of network availability.
- PoE (IEEE 802.3af) and 12VDC Power Options — Maximum power consumption of 4.4W enables standard PoE deployment over single Ethernet run; 12VDC±25% alternative supports legacy analog infrastructure upgrades.
i-PRO M-46-FW-V3 Integration & Compatibility
Supports ONVIF Profiles G, S, and T for standardized IP camera integration across Milestone XProtect, Genetec Security Center, and other enterprise VMS platforms. Network protocols include IPv4, TCP/UDP, RTSP, RTMP, HTTP/HTTPS, SMTP, SNMP, and FTP; 802.1X and SSL/TLS enable secure network authentication and encrypted communication. Single RJ45 10M/100M Base-TX Ethernet interface connects to PoE switches, midspans, or standard 12VDC supplies. Pan/tilt mechanical adjustment (Pan 8–360°, Tilt 0–68°, Rotate 10–360°) accommodates wall, soffit, and corner mounting. The camera operates across -30°C to 60°C (-22°F to 140°F) temperature range and tolerates up to 95% humidity (non-condensing), meeting demanding outdoor seasonal deployment requirements.
i-PRO M-46-FW-V3 Compliance & Security
NDAA compliant for U.S. federal and sensitive sector deployments. Certified CE LVD (EN 62368-1), UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1), FCC (47 CFR Part 15B), and CE-EMC (EN 55032, EN 55035, EN IEC 61000-3-2/3-3). No software license required for use with Video Insight VMS. Signal-to-noise ratio >52dB and automatic/manual shutter control (1–1/100,000 s) ensure image clarity across dynamic light conditions.
