i-PRO M-46-F-V2 Overview
The i-PRO M-46-F-V2 is a compact 4MP fixed dome network camera designed for outdoor surveillance in demanding environments. Built on a 1/2.7" progressive scan CMOS sensor, this camera delivers sharp detail at 2688 x 1520 resolution with a 4mm fixed lens optimized for general-purpose coverage. The M-46-F-V2 combines robust weatherproofing (IP67, IK10 vandal-resistant rating) with powerful low-light performance, making it suitable for retail, perimeter, and mixed indoor/outdoor deployments where durability and reliability are critical.
i-PRO M-46-F-V2 Key Features
- 4MP sensor with 120dB Wide Dynamic Range — Captures detail in mixed lighting conditions with automatic exposure control; F1.6 aperture supports 0.003 lux in color mode and 0 lux with IR for true day/night operation.
- 30-meter infrared range with built-in IR-cut filter — Delivers up to 98 feet of IR illumination with auto-switching ICR (IR-cut filter) for seamless color-to-monochrome transition and reliable night vision across the full detection envelope.
- 91.2° horizontal field of view (4mm fixed lens) — Provides wide coverage suitable for entrance monitoring, corridors, and general perimeter surveillance; DORI specifications support detection at 90m, observation at 36m, recognition at 18m, and identification at 9m.
- Vandal-resistant dome enclosure with IK10 rating — Engineered to withstand impact and tampering; IP67 weatherproofing ensures operation in rain, dust, and corrosive environments from -30°C to +60°C (-22°F to +140°F).
- Ultra 265, H.265, and H.264 video compression — Supports efficient bandwidth management with bitrate range of 128 Kbps to 16 Mbps; dual-stream capability enables simultaneous recording and streaming at different resolutions.
- Built-in microphone with G.711U/G.711A audio compression — Captures ambient sound for forensic review; includes audio detection analytics for event-driven alerts and incident investigation.
- Advanced video analytics — Cross-line detection, intrusion detection, human body detection, motion detection, tampering alarm, and audio detection provide multi-layer alerting without external middleware.
- PoE and 12VDC dual power support — Accepts PoE (IEEE 802.3af) or DC 12V ±25%, consuming maximum 4.5W; field-flexible installation via single RJ45 interface with 10M/100M Base-TX Ethernet.
- 3-axis mechanical adjustment — Pan 8° to 360°, tilt 0° to 68°, and rotate 10° to 360° for precise aiming and minimized installation labor; enables flexible wall, ceiling, and corner mounting.
- MicroSD local storage (up to 256GB) and edge processing — On-device recording and analytics reduce dependency on central NVR; supports redundant or standalone configurations with high-capacity card support.
- Comprehensive image processing suite — Smart IR, HLC (highlight compensation), BLC (backlight compensation), defog, digital noise reduction, white balance, and ROI coding (up to 8 regions) optimize image quality across varied scenes.
- Enterprise-grade network security — IPv4 stack with SSL/TLS encryption, HTTPS support, 802.1X network authentication, DDNS for dynamic addressing, and SNMP for remote management; complies with CE (EN 62368-1) and UL (UL 62368-1) safety standards.
i-PRO M-46-F-V2 Integration & Compatibility
The M-46-F-V2 integrates with any ONVIF-compliant VMS platform via its comprehensive network protocol stack (IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL/TLS). Direct integration with i-PRO VideoInsight VMS requires no additional licensing. The single RJ45 Ethernet interface (10M/100M) supports both remote viewing and control; firmware supports FTP for automated backup and upgrade workflows. Mounting options include junction box (M-JB-MINI), wall mounts (M-WM-JB-MINI-V2, M-WM-MINI), pole mounts (M-PM-B-V2), and pendant configurations for flexible deployment across fixed-mount applications.
i-PRO M-46-F-V2 Package Contents
- i-PRO M-46-F-V2 4MP dome camera unit
- M-JB-MINI junction box (standard accessory)
- M-NPT34 mounting hardware
