i-PRO M-45-FW-V2 4MP Low Profile Indoor Dome Camera

i-PRO M-45-FW-V2 Overview

The i-PRO M-45-FW-V2 is a 4MP fixed dome network camera engineered for indoor surveillance deployments. This compact, low-profile model delivers wide-angle monitoring with integrated infrared illumination, built-in microphone, and advanced video analytics—designed for integration into enterprise VMS environments and surveillance networks where space and cable management are critical.

i-PRO M-45-FW-V2 Key Features

• 4MP Progressive Scan CMOS Sensor — 1/2.7" image sensor captures 2688 x 1520 resolution at 30 fps, delivering sharp detail for facial recognition and object identification in indoor environments.
• 120dB Wide Dynamic Range (WDR) — Handles mixed lighting conditions and scenes with bright windows or skylights, maintaining usable image detail across highlight and shadow areas without ghosting artifacts.
• 2.8mm Fixed Lens with F1.6 Aperture — 101.1° horizontal field of view and 55.3° vertical FOV provide expansive coverage; F1.6 aperture enables low-light performance. DORI distances: 63m detect, 25.2m observe, 12.6m recognize, 6.3m identify.
• Built-in IR LED Illumination up to 30 Meters — IR-cut filter with automatic day/night switching (ICR) ensures true color in daylight and monochrome operation in darkness; 0 lux capability with IR enabled. Min illumination in color: 0.003 lux at F1.6 with AGC.
• Integrated Microphone — Audio input impedance 35kΩ, amplitude 2V [p-p], with G.711U and G.711A compression support for two-way audio and event-triggered audio detection. Audio output also available (600Ω impedance, 2V [p-p]).
• Advanced Video Compression — Supports Ultra H.265, H.265, H.264, and MJPEG; tri-stream capability allows simultaneous delivery of multiple resolutions and codecs to different clients. Video bitrate: 128 Kbps–16 Mbps.
• Embedded Analytics — Intrusion detection, human body detection, motion detection, tampering alarm, and audio detection; up to 8 regions of interest (ROI) with independent codec settings for bandwidth optimization.
• 3-Axis Mechanical Adjustment — Pan 0–348°, tilt -66° to +66°, rotate 0–346° allow precise mounting alignment without additional pan-tilt hardware; compact form factor simplifies ceiling or corner installations.
• PoE and DC 12V Power Supply — IEEE 802.3af PoE (standard power) or 12V DC ±25% operation; maximum power consumption 4.5W supports single-cable installations and simplified cabling infrastructure.
• Onboard Edge Storage — microSD card slot supports up to 256GB for local backup and failover recording; eliminates dependency on central NVR during network interruptions.
• Standards-Based Networking — IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, and QoS support; 10M/100M Base-TX Ethernet interface; 1 alarm input and 1 alarm output channel.
• Compact Low-Profile Design — Ø109 × 62mm (4.3" × 2.4") form factor and 0.22kg (0.49 lbs) weight simplify discrete ceiling mounting in offices, retail, and educational facilities where aesthetics matter.

i-PRO M-45-FW-V2 Operating Conditions & Certifications

Operates reliably in temperature ranges from -30°C to +55°C (-22°F to +131°F) with humidity up to 95% RH non-condensing, suitable for climate-controlled indoor environments. Complies with IEC 62368-1, EN 62368-1, and UL 62368-1 safety standards; FCC Part 15, EN 55032, EN 55035, EN 61000-3-2, and EN 61000-3-3 EMC regulations ensure compatibility with enterprise IT networks. No software license required for use with Video Insight VMS platform.

i-PRO M-45-FW-V2 Integration & Compatibility

ONVIF-compliant network interface ensures interoperability with third-party VMS platforms, access control systems, and management software. Standard protocols (RTSP, HTTP, HTTPS, DHCP, DNS, NTP, FTP) enable seamless integration into IP surveillance networks. Alarm input/output channels support external trigger devices and relay-controlled actions. microSD edge storage enables local recording independent of backend infrastructure.
