Frame Rate:
20fps
Sensor Type:
1/2.9" Progressive Scan CMOS
Max. Resolution:
2944 × 1656
Min. Illumination:
Color: 0.01 lux @(F1.2, AGC ON), 0.028 Lux @(F2.0, AGC ON), B/W: 0 lux with IR
Shutter Time:
1/3 s to 1/100,000 s
Day & Night:
IR cut filter
Angle Adjustment:
Pan: 0° to 355° , tilt: 0° to 75°, rotate: 0° to 355°
Lens Type:
Fixed focal lens, 2.8, 4, and 6 mm optional
Focal Length & FOV:
2.8 mm, horizontal FOV: 97°;4 mm, horizontal FOV: 78°;6 mm, horizontal FOV: 60°
Lens Mount:
M12
Iris Type:
Fixed
Aperture:
F2.0
Supplement Light Type:
IR
Supplement Light Range:
Up to 30 m
Main Stream:
50 Hz: 20 fps (2944 × 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720);60 Hz: 20 fps (2944 × 1656), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream:
50 Hz: 25 fps (640 × 480, 640 × 360, 320 × 240);60 Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
Third Stream:
50 Hz: 25 fps (1280 ×720, 640 × 360, 352 × 288);60 Hz: 30 fps (1280 ×720, 640 × 360, 352 × 240)
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264;Sub-stream: H.265/H.264/MJPEG;Third stream: H.265/H.264
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Main Profile/High Profile
H.265 Type:
Main Profile
Region Of Interest (ROI:
1 fixed region for main stream and sub-stream separately
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM/MP3
Audio Bit Rate:
64 Kbps(G.711)/16 Kbps(G.722.1)/16 Kbps(G.726)/32 Kbps to 192 Kbps(MP2L2)/8 Kbps to 320 Kbps(MP3)
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz
Environment Noise Filtering:
Yes
Protocols:
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Simultaneous Live View:
Up to 6 channels
API:
Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK
User/Host:
Up to 32 users. 3 user levels: administrator, operator and user
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video I
Network Storage:
NAS (NFS,SMB/CIFS), ANR
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Plug-in required live view: IE8+;Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+;Local Service: Chrome 41.0+, Firefox 30.0+
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance adjustable by client software or web browser
Day/Night Switch:
Day/Night/Auto/Schedule/Triggered by Alarm In(-S)
Wide Dynamic Range (WDR:
120 dB
Image Enhancement:
BLC/3D DNR/HLC
Ethernet Interface:
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage:
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 128 GB
Audio Support:
1 audio input (line in), 1 audio output interface, mono sound, terminal block
Alarm:
1 alarm input, 1 alarm output (max. 12 VDC, 30 mA), terminal block
Reset Key:
Yes
Basic Event:
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event:
Line crossing detection, intrusion detection, unattended baggage detection, object removal detection, face detection, scene change detection
Linkage:
Trigger recording: memory card, network storage, pre-record and post-record;Trigger captured pictures uploading: FTP, HTTP, NAS, Email;Trigger notification: HTTP, ISAPI, alarm output (-S), Email
Power Type:
12 VDC ± 25%, 6.2 W;PoE: 802.3af, class 3, 36 V to 57 V, 9 W
Dimension:
Ø111 × 82.4 mm (Ø4.4" × 3.2")
Package Dimension:
134 × 134 × 108 mm (5.3" × 5.3" × 4.3")
Weight:
500 g (1.1 lb.)
Startup And Operating Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language:
32 languages;English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditiona
General Function:
Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
Protection:
IP67 (IEC 60529-2013);IK10 (IEC 62262: 2002)
