Features:
AI
Frame Rate:
Variable
Sensor Type:
5MP 1/2.7 CMOS sensor
Maximum resolution:
5MP
Minimum Scene Illumination in color:
0.0 lux (B/W), 0.02 lux (color)
Total Pixels:
2592 (H) × 1944 (V)
Focal Length:
2.8mm, 3.6mm
Horizontal Field of View (HFOV:
81.4°, 98.5°
IR Distance:
100' range Smart IR™
Lens Type:
Fixed Lens
Audio compression:
G.711A / U
I/O Audio in/out:
*Cameras provide a line level audio. The use of amplified microphones and speakers is recommended., 1 input, 1 microphone built-in
3D digital noise reduction:
Smart DNR™ 3D Digital Noise Reduction
Auto gain control:
Auto
Camera Analytics:
Object Classification (Differentiate Humans from Objects), Line Crossing, Perimeter Intrusion, video Tampering Detection (Scene Change, Video Blur, Abnormal Color Detection)
Day and Night:
Auto day/night, Day (color), Night (B/W)
De-fog:
Yes
Memory slot:
Micro SD/SDHC/SDXC class 10 card (card not included), Up to 1TB micro SD / FAT32
Mirror/flip:
Yes
Motion Detection:
Yes
Operational Notifications:
Email, FTP server
Privacy Zones:
4 programmable privacy masks
Sharpness:
Yes
Shutter Mode:
Auto, Manual
Shutter Speed:
1/30 ~ 1/100000
White Balance:
Yes
Wide Dynamic Range (WDR:
True WDR 120dB
Bitrate Control:
Multi-streaming CBR/VBR at H.264, H.265 (controllable frame rate and bandwidth)
IP:
IPv4, IPv6
LAN:
802.3 compliance 10/100 LAN
Network resolution:
5MP, 4MP, 2K, 3MP, 2.1MP/1080P, 720P (60Hz: 1 ~ 30fps; 50Hz: 1~25fps), HFR mode: 1080P / 720P (60Hz: 1 ~ 60fps; 50Hz: 1~50fps)
Network Web Viewer:
Microsoft Edge® browser, Windows® OS
Protocol:
802.1x, DDNS, DHCP, FTP, HTTP, HTTPs, ICMP, IGMP, NTP, ONVIF, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, SNMP, UDP, UPnP
Security:
Digest authemtication (ID/PW), IP filtering, MAC filtering
Stream Speed:
Up to 30fps at all resolutions
Streaming Capability:
Dual-stream at different rates and resolutions
Video Bitrate:
64Kbps~8Mbps
Video Compression Type:
H.264, H.265, MJPEG
Video Management Software:
Any ONVIF conformant CMS, DW Spectrum® IPVMS, ExacqVision Technologies, Milestone Systems
Environmental Operating Humidity:
0-95% RH (non–condensing)
Environmental Operating Temperature:
-22°F ~ 140°F (-30°C ~ 60°C)
Mounting Accessories (Required/Optional:
Optional. Sold separately
Camera Dimensions (H X W X D:
4.66" x 3.58" (118.6 x 91 mm)
Camera Weight:
1.01 lbs (0.46 kg)
Housing:
Turret
Housing Color:
White
IK rating:
IK10 Rated
IP Rating:
IP67
Materials:
Aluminum die-casting
Power Consumption:
DC12V: max 7.0W, 583.3mA, PoE: max 7.0W
Power Requirements:
Adapter not included, PoE
Warranty:
5 Year Warranty
Product Type:
Turret
Connectivity:
Wired
Power Type:
PoE
Resolution:
5MP
Night Vision:
IR
Form Factor:
Dome
Analytics Support:
LPR
Outdoor Ready:
Yes
WDR:
WDR
