Hanwha PNM-C16083RVQ B2 B Stock: P series network vandal outdoor

Hanwha PNM-C16083RVQ B2 Overview

The Hanwha PNM-C16083RVQ B2 is a 4-channel multi-directional network camera designed for outdoor vandal-resistant deployment. This B-stock unit combines robust IP66/IK10 construction with motorized varifocal optics (3.3–5.7mm, 100° H FOV) and delivers 4MP resolution at 30 fps across all channels, making it suitable for perimeter security, facility monitoring, and high-traffic surveillance environments.

Hanwha PNM-C16083RVQ B2 Performance & Video Features

• 4MP resolution per channel at 30 fps
• Motorized varifocal lens 3.3–5.7mm with 100° horizontal field of view
• 120dB wide dynamic range for high-contrast outdoor scenes
• 20m (65.6 ft) IR illumination range for night vision
• Triple codec support: H.265, H.264, MJPEG for flexible streaming and storage optimization
• PoE+ (802.3at) powered for simplified field installation

Hanwha PNM-C16083RVQ B2 Durability & Environmental Rating

• IP66 dust and water ingress protection
• IK10 impact resistance (vandal-resistant)
• NEMA 4X rated enclosure
• Designed for outdoor mounted installations

Hanwha PNM-C16083RVQ B2 Analytics & Intelligence

• AI-driven object detection: Person, vehicle (car/truck/bus), bicycle, and motorcycle classification
• Intelligent Video Analytics (IVA): virtual line crossing, area intrusion, loitering detection, direction analysis, and enter/exit events
• Appear/Disappear detection for object tracking
• WiseNR noise reduction and WiseStream bandwidth optimization via AI engine
• I/O Box compatible for alarm relay and sensor integration

Hanwha PNM-C16083RVQ B2 Security & Integration

• TPM with FIPS 140-2 Level 2 cryptographic support
• USB port for on-site management and configuration
