Axis Q3536-LVE 4MP OptimizedIR Outdoor PTZ Dome

Axis Q3536-LVE 4MP OptimizedIR Lightfinder Forensic WDR Outdoor PTZ Dome IP Camera

The Axis Q3536-LVE is a high-performance outdoor PTZ dome camera engineered for demanding surveillance environments. Delivering 4MP resolution at up to 60fps with Lightfinder 2.0 technology, this camera captures forensic-quality imagery in extreme low-light conditions—down to 0.06 lux in color mode. Built for reliability in harsh outdoor settings, the Q3536-LVE combines advanced optical performance with robust physical protection and enterprise-grade security features.

Key Features

• 4MP CMOS sensor (1/1.8") with 2688x1512 resolution and 60fps capture
• Lightfinder 2.0 technology for superior low-light color saturation and detail
• Forensic WDR (Wide Dynamic Range) for balanced exposure in mixed lighting
• OptimizedIR with built-in IR illumination and IR-shielded dome for reflection-free imaging
• Motorized pan-tilt-zoom with dual focal lengths: 4.3–8.6mm and 11.3–29.4mm
• Horizontal field of view: 103–52° (wide) and 14.9–40.8° (tele)
• Electronic image stabilization for smooth video despite vibration or wind
• H.264 compression with Zipstream support for optimized bandwidth
• IP66 and IK10+ ratings—weatherproof and vandal-resistant
• PoE Class 4 powered with audio support
• Operating temperature range: -50 to +55°C

Advanced Capabilities

The Q3536-LVE excels in round-the-clock surveillance with its combination of Lightfinder 2.0 and Forensic WDR. Lightfinder technology amplifies low-light performance while preserving color detail, making it ideal for identifying subjects in twilight or nighttime conditions. The built-in optimized IR provides supplementary illumination without reflection artifacts from the dome. Forensic WDR handles scenes with extreme contrast—such as entry points with bright backgrounds and dark shadows—ensuring usable detail across the entire frame.

The dual zoom capability enables broad area coverage at wide angle (103°) while supporting tight, forensic-quality zooms at tele focal length (40.8°). Remote focus and zoom via PoE simplify installation and adjustment without physical access to the camera. H.264 compression paired with Zipstream technology reduces storage and bandwidth demands without sacrificing image quality.

Security & Durability

Designed for outdoor permanence, the Q3536-LVE meets IP66 (dust and water resistance) and IK10+ (vandal resistance) standards. Its wide operating temperature range ensures consistent performance from arctic to desert climates. Built-in security measures include signed firmware, secure boot, and Axis Edge Vault for encrypted credential storage—protecting against unauthorized access and tampering.

Applications

• Perimeter surveillance at airports, seaports, and industrial facilities
• Campus and facility monitoring in variable lighting conditions
• Traffic monitoring and intersection coverage
• Critical infrastructure protection requiring forensic-quality video
• Outdoor premises monitoring in extreme climates

Eden Phillips

The Q3536-LVE represents Axis's premium outdoor PTZ offering, balancing forensic imaging quality with practical operational durability. The Lightfinder 2.0 + Forensic WDR combination addresses a critical surveillance gap: most PTZ cameras struggle to deliver usable color detail at night, forcing operators to choose between IR monochrome and poor color performance. This camera avoids that trade-off.

The dual zoom range is well-suited for wide-area monitoring with tactical zoom capability—a necessity for outdoor perimeter work. The IK10+ rating and -50 to +55°C operating range make it genuinely field-hardened, not merely weatherproof. For organizations requiring forensic-grade outdoor video in dynamic lighting, this is a top-tier choice, though budget-conscious deployments should evaluate whether Lightfinder 2.0 justifies the premium over standard low-light cameras.

Download Product Datasheet (PDF)
