Sensor Type:
1/1.2.7ʺ Progressive Scan CMOS
Max. Resolution:
1920 × 1080
Min. Illumination:
Color: 0.005 Lux @ (F1.2, AGC ON), 0.0176 Lux @ (F2.25, AGC ON);B/W: 0.001 Lux @ (F1.2, AGC ON), 0.0035 Lux @ (F2.2.5, AGC ON)
Shutter Time:
1/25 s to 1/100,000 s
Day & Night:
IR cut filter
Lens Type:
Fixed focal lens, 2 mm
Focal Length & FOV:
Horizontal FOV 104.5°, vertical FOV 70.5°, diagonal FOV 112°
Lens Mount:
M12
Aperture:
F2.25
Supplement Light Type:
IR
Supplement Light Range:
Up to 6 m
IR Wavelength:
850 nm
Main Stream:
50 Hz: 25 fps (1920 × 1080, 1280 × 720); 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream:
50 Hz: 25 fps (704 × 576, 640 × 480);60 Hz: 30 fps (704 × 480, 640 × 480)
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264;Sub stream: H.265/H.264/MJPEG
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
BaseLine Profile/Main Profile/High Profile
H.265 Type:
Main Profile
Scalable Video Coding (SVC:
H.265 and H.264 support
Region Of Interest (ROI:
4 fixed regions for main stream and sub-stream
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate:
64 Kbps(G.711)/16 Kbps(G.722.1)/16 Kbps(G.726)/32 to 160 Kbps(MP2L2)
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering:
Yes
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Simultaneous Live View:
Up to 20 channels
API:
Open Network Video Interface (Profile S, Profile G), ISAPI, SDK, Ehome (5.0)
User/Host:
Up to 32 users. 3 user levels: administrator, operator and user
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTTPS, control timeout
Client:
iVMS-4200, Hik-Connect
Web Browser:
IE8+, Chrome 41.0-44, Mozilla Firefox30.0-51, Safari8.0-11
Image Settings:
Saturation, brightness, contrast, sharpness are adjustable by client software or web browser
Day/Night Switch:
Day/Night/Auto/Schedule/Triggered by alarm input (-S)
Wide Dynamic Range (WDR:
Digital WDR
Image Enhancement:
HLC, BLC, 3D DNR, defog
Picture Overlay:
LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
Ethernet Interface:
1 RJ45 10 M/100 M Ethernet port, -S: 1 RS-485 interface (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
On-Board Storage:
300 M eMMC storage for people counting data
Audio Support:
1 built-in microphone;-S: 1 input (line in, two-core terminal block), 1 output (two-core terminal block), mono sound
Alarm:
1 input, 1 output (max. 24 VDC, 1 A)
Basic Event:
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Linkage:
Upload to FTP/NAS, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture
People Counting:
Counts people entering and exiting separately;Supports real-time uploading and uploading by statistic cycle;Sends email reports on daily, weekly, monthly or annually basis;Supports target filtering by height
Power Type:
12 VDC ± 20%, 0.66 A, max. 8 W, reverse polarity protection, Ø5.5mm coaxial power plug;PoE: 802.3 af, class 3, 36 to 57 V, 0.23 A to 0.14 A, max. 8.3 W
Dimension:
With -V: 168 mm × 61 mm × 41 mm (6.6" × 2.4 × 1.6" )
Weight:
Camera: Approx. 435 g (1 lb.);With package: 725 g (1.6 lb)
Storage Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions:
-30 °C to 45 °C (-22 °F to 113 °F). Humidity 95% or less (non-condensing)
Language:
32 languages. English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Tradition
General Function:
Anti-flicker, heartbeat, mirror, password protection, watermark, IP address filter
EMC:
FCC (47 CFR Part 15, Subpart B);CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014);RCM (AS/NZS CISPR 32: 2015);IC (ICES-003: Issue 7);KC (KN32: 2015, KN35: 2015)
Safety:
UL (UL 62368-1);CB (IEC 62368-1: 2014+A11);BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005)
Environment Rating:
CE-RoHS (2011/65/EU);WEEE (2012/19/EU);Reach (Regulation (EC) No 1907/2006)
Protection:
With -V model: IP67 (IEC 60529-2013)
Product Type:
Accessory
Connectivity:
Wired
Resolution:
2MP
Night Vision:
IR
