Hanwha WRR-P-E201S2-32TB 1U WAVE Network Video Recorder with 4

Hanwha WRR-P-E201S2-32TB Overview

The Hanwha WRR-P-E201S2-32TB is a 1U rackmount Wisenet WAVE Network Video Recorder designed for professional surveillance deployments requiring enterprise-grade reliability and high-density video storage. This model arrives pre-installed and configured with Wisenet WAVE video management software and includes 4 Professional licenses, eliminating deployment delays. With 32TB raw storage (21TB usable after RAID 5 formatting) and sustained 470 Mbps recording bandwidth, it supports up to 128 IP camera channels and scales to meet mid-to-large installations without requiring external storage expansion.

Hanwha WRR-P-E201S2-32TB Key Features

• 32TB Raw Storage with RAID 5 Flexibility — Supports up to 80TB raw capacity across four 3.5" hot-swappable HDD bays. The WRR-P-E201S2-32TB ships with 32TB raw storage, providing 21TB usable capacity after RAID 5 formatting and disk overhead. RAID 0, 1, 5, and 6 configurations are supported for data protection and performance optimization.
• High-Throughput Recording at 470 Mbps — Delivers 470 Mbps sustained recording bandwidth, enabling simultaneous ingest from numerous high-resolution IP cameras without bottlenecking. Sufficient for 4K multi-camera environments and future-proof for H.265-compressed streams.
• Intel Xeon 6333P Processor with 16GB DDR5 RAM — Enterprise-class processor paired with 16GB of DDR5 memory (2x8GB) ensures smooth VMS operation, rapid search and playback, and stable handling of analytics workloads without performance degradation under load.
• NVIDIA T400 Graphics Card — Dedicated GPU accelerates video decoding and display rendering, enabling smooth multi-monitor output and reducing CPU overhead for real-time video operations.
• Dual 480GB SSD OS Drives in RAID 1 — Mirrored operating system drives provide redundancy and fast boot times. Failures are transparently handled without service interruption.
• Windows Server 2022 with Wisenet WAVE Pre-Installed — Arrives running Windows Server 2022 Standard with Wisenet WAVE VMS fully configured. Four included Professional licenses support advanced features including multi-server deployments and role-based access control. Alternative OS options (Windows 11 IoT Enterprise LTSC 2024 or Ubuntu 22.04 LTS) available via special order.
• 512MB NV Cache — Non-volatile write cache improves disk I/O performance and protects against data loss during power transients or unexpected shutdown.
• Redundant 450W 80 Plus Platinum Power Supplies — Dual power supplies with automatic failover ensure continuous operation during single PSU failure. 80 Plus Platinum efficiency reduces heat generation and operational cost.
• Comprehensive Video Output Options — Single HDMI, single VGA, and four Mini DisplayPort outputs support multi-monitor surveillance walls and independent operator stations. USB 3.2 ports (2x front, 2x rear) enable external device integration and firmware updates.
• Dual 1GbE Network Interfaces — Standard configuration includes two RJ45 Gigabit Ethernet ports for camera connectivity and network redundancy. Optional upgrade to dual 1GbE + dual 10GbE provides bandwidth for very high-density deployments.
• IPMI Management Support — Out-of-band management interface enables remote power control, temperature monitoring, and system diagnostics without relying on OS availability.
• Supports Wisenet and ONVIF Conformant Cameras — Compatible with Hanwha Wisenet cameras and any ONVIF-compliant IP camera from third-party vendors, providing vendor flexibility and integration with existing infrastructure.

Hanwha WRR-P-E201S2-32TB Integration & Compatibility

The WRR-P-E201S2-32TB runs Windows Server 2022 Standard and ships with Wisenet WAVE VMS pre-installed and fully configured. It supports up to 128 IP camera channels and is compatible with Wisenet and ONVIF-conformant cameras, allowing integration into heterogeneous surveillance networks. Dual 1GbE network interfaces support both camera connectivity and management traffic; optional 10GbE uplinks are available for high-throughput environments. IPMI support enables enterprise remote management tools to monitor system health, power state, and thermal conditions. The included rail kit with cable management arm simplifies 19" rack installation and maintains airflow discipline.

Hanwha WRR-P-E201S2-32TB Package Contents

• Hanwha WRR-P-E201S2-32TB 1U rackmount chassis with 32TB HDD storage
• Wisenet WAVE VMS pre-installed and configured on Windows Server 2022 Standard
• 4x Wisenet WAVE Professional licenses
• USB keyboard and mouse
• Sliding rack rail kit with cable management arm
• Redundant 450W 80 Plus Platinum power supplies with cables
