Sensor Type:
1/2.7" Progressive CMOS
Resolution:
SD: 1280 x 960, HD: 2560 x 1920
Lens Types:
Motorized, Vari focal, Remote Focus
Focal Length:
f= 2.8 ~ 10 mm
Aperture:
F1.8(W) ~ F2.74(T)
Iris:
Fixed iris
Field of View:
95°~41° (Horizontal), 69°~31° (Vertical), 127°~51° (Diagonal)
Camera Movement:
Pan 350° Tilt: 80° Rotate:±175°
Shutter Speed:
1/5 sec. to 1/32,000 sec.
Day/Night:
Yes
IR Cut Filter:
Yes
IR Distance:
30 meters
WDR Technology:
WDR Pro
Minimum Illumination:
0.06 lux @ F1.8 (Color), 0.01 lux @ F1.8 (B/W), 0 lux with IR illumination on
Onboard Storage:
MicroSD/SDHC/SDXC card slot, (Built in 256GB industrial SDCard)
Frame Rate:
15FPS
Video Streaming Settings:
HD Video 2560 x 1920@15fps 1.2Mbps upload, SD Video 1280 x 960@15fps 300Kbps upload
Audio Support:
One way Audio
Effective Range:
5 meters
Audio detection:
Yes
Tampering detection:
Yes
People Analytics:
Intrusion detection, Line crossing detection, Loitering detection, Scene Search
Vehicle Analytics:
Intrusion detection, Line crossing detection, Loitering detection, Scene Search
Object Analytics:
Unattended object detection, Missing object detection
Input Voltage:
IEEE 802.3af PoE Class 0
Power (Max:
Max. 9.7 W (IR on), Max. 7.3 W (IR off)
Connectivity:
RJ 45 cable connector for 10/100 Mbps PoE network connection
RTSP:
WebRTC, ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IPv4, IPv6, NTP, QoS (CoS/DSCP), RTSP/RTP/RTCP, SSL, TCP/IP, TLS 1.2, UDP
Users:
Up to 6 clients, *Live viewing for 6 clients, *live viewing up to 4 clients and playback 2 clients)
Security:
Secure boot, Signed firmware, HTTPS/TLS encryption, Video encryption
Interface:
10 Base T/100 Base TX Ethernet (RJ 45)
Operating Temperature:
Starting Temperature: 0°C ~ 50°C (32°F ~ 122°F), Working Temperature: 10°C ~ 50°C (14°F ~ 122°F) (IR off), 10°C ~ 45°C (14°F ~ 113°F) (IR on)
Humidity:
90% RH (non condensing)
Features:
EMC: CE (EN55032, EN55024 Class B, E50121 4), FCC (FCC Part 15 Subpart B Class B), RCM (AS/NZS CISPR32 Class B), VCCI (VCCI CISPR 32 Class B); Safety : UL (UL62368 1), CB (IEC/EN 62368 1, IEC/EN 60950 22, IEC/EN 62471)
Warranty:
120 month
Included Accessories:
Quick installationuide, alignment sticker, screw pack
Weight:
355g
Dimensions:
Ø 130 x 95 mm
Body:
Plastic
Product Type:
Box
Power Type:
PoE
Night Vision:
IR
