Vivotek Vortex FD819 H 5MP Outdoor WDR Pro Fixed Microphone IP Camera

Vivotek FD819-H 5MP Outdoor WDR Pro IP Camera

The Vivotek Vortex FD819-H is a professional-grade 5MP outdoor IP camera engineered for comprehensive surveillance in demanding environments. Combining high-resolution imaging with advanced wide dynamic range technology, this fixed-lens camera delivers exceptional clarity across varying lighting conditions. Its integrated microphone and robust analytics suite make it an ideal choice for businesses requiring reliable perimeter monitoring, access control, and intelligent threat detection.

Key Features

• 5MP Resolution (2560 x 1920) with 15 FPS streaming
• WDR Pro Technology for balanced exposure in high-contrast scenes
• 103° horizontal field of view with fixed 2.8mm lens (F2.0 aperture)
• Day/Night capability with 30-meter IR illumination and IR cut filter
• One-way audio with 5-meter effective range and audio detection
• Built-in 256GB industrial microSD card for local recording
• PoE power (IEEE 802.3af Class 0) — maximum 6.3W with IR on
• IP66-rated weatherproof enclosure for outdoor durability
• Compact dome design (Ø130 x 95mm, 350g)

Technical Highlights

The FD819-H excels in low-light environments, achieving 0.06 lux color sensitivity and 0.01 lux monochrome sensitivity at F2.0. Its variable shutter speed (1/5 to 1/32,000 sec.) ensures optimal exposure from dawn to dusk. The camera supports HD and SD video streaming at 1.2 Mbps and 300 Kbps respectively, optimizing bandwidth for remote monitoring. Pan/tilt/rotate capability (350° pan, 80° tilt, ±175° rotation) provides flexible installation and framing.

Analytics & Intelligence

Embedded analytics include people detection (intrusion, line crossing, loitering, scene search), vehicle detection (same analytics), and object monitoring (unattended and missing object detection). Tampering detection alerts operators to unauthorized camera interference, enhancing security integrity.

Security & Connectivity

The camera integrates HTTPS/TLS 1.2 encryption, secure boot, signed firmware, and video encryption to protect surveillance data. It supports up to 6 simultaneous clients with configurable playback and live-view streams. Compliance includes CE, FCC, RCM, and UL certifications. Operating temperature range spans 0–50°C, with humidity tolerance to 90% RH non-condensing, ensuring reliable year-round deployment.

Applications

Ideal for parking lots, building entrances, perimeter fencing, loading docks, and access points requiring weather-resistant, intelligent surveillance. The one-way audio and audio detection enhance situational awareness and incident response.

Eden Phillips

The FD819-H represents solid mid-range outdoor surveillance with practical intelligent features. WDR Pro effectively handles backlit scenes common in parking and entryway deployments. The 5MP resolution provides useful detail for facial recognition and license plate capture at moderate distances.

Built-in analytics reduce backend processing load, while the industrial-grade microSD card ensures local recording continuity during network interruptions. PoE efficiency (under 7W peak) simplifies installation. Notably, the compact form factor and fixed lens limit customization but reduce installation complexity.

The 120-month warranty reflects manufacturer confidence in durability, though field-verifiable performance in extreme weather should precede large deployments.
