Vivotek AW-FGT260F380 24-Port PoE+ Switch

Vivotek AW-FGT260F380 24-Port PoE+ Unmanaged Switch

The Vivotek AW-FGT260F380 is a robust unmanaged network switch purpose-built for IP surveillance and security deployments. With 24 Fast Ethernet PoE+ ports and a generous 380W total power budget, this switch delivers reliable power and data connectivity to multiple high-powered IP cameras and networked security devices simultaneously. The dual Gigabit Ethernet combo ports provide high-speed uplink capacity, while the plug-and-play design eliminates configuration complexity—ideal for rapid deployment in enterprise security environments.

Key Features

• 24 x 10/100Mbps PoE+ Ports – IEEE 802.3af/at compliant with up to 30W per port
• 2 x Gigabit RJ45/SFP Combo Uplink Ports – Flexible high-bandwidth connectivity
• 380W Total PoE Power Budget – Simultaneously power multiple high-draw devices
• 8 Extended Mode PoE Ports – 250M cable run capability at 10Mbps for extended reach
• 8.8 Gbps Switching Capacity – Efficient non-blocking architecture
• Unmanaged Design – No software configuration required; instant plug-and-play deployment
• VLAN Support – Segment network traffic for enhanced security and performance
• Auto-MDI/MDI-X & Auto-Negotiation – Compatible with standard and crossover cables

Technical Specifications

• Ports: 24 x 10/100Mbps PoE+, 2 x Gigabit RJ45/SFP Combo
• PoE Power Output: 54VDC; IEEE 802.3af (15.4W max) and IEEE 802.3at (30W max)
• PoE Surge Protection: 6KV; AC Surge Protection: 4KV
• MAC Table: 16K entries
• Jumbo Frame Support: Up to 1,536 bytes
• Power Input: 100VAC–240VAC, 280VAC (4 hours), 300VAC (1 minute)
• Operating Conditions: 0°C to 50°C; 10–90% humidity (non-condensing)
• Dimensions: 440 x 207 x 44 mm; Weight: 3.25 kg
• Certifications: CE, UKCA, FCC, VCCI, C-Tick Class A; EN62368-1, IEC62368-1
• Warranty: 24 months

Applications

• IP surveillance and CCTV infrastructure
• Enterprise security camera networks
• Access control and building automation systems
• Industrial monitoring and edge deployment
• Multi-tenant office and campus environments

Why Choose the AW-FGT260F380?

This unmanaged switch combines industrial-grade durability with practical features designed for security integrators and facility managers. The 380W power budget accommodates modern high-resolution cameras with PTZ and infrared capabilities, while extended mode PoE ports enable installations in challenging layouts. Built-in surge protection (6KV PoE, 4KV AC) safeguards equipment in environments prone to electrical stress. Wide operating temperature range (0–50°C) and robust EMC certification ensure reliable performance in diverse settings—from climate-controlled data centers to outdoor utility enclosures.

Marty Allison

The AW-FGT260F380 is engineered for scalable surveillance deployments where managed features are unnecessary but power delivery and reliability are critical. Its 8.8 Gbps switching fabric handles concurrent video streams without bottlenecking, while per-port PoE auto-detection reduces cabling errors. Eight extended mode ports (supporting 250M runs at 10Mbps) add flexibility for distributed camera placement beyond standard 100m Ethernet limits.

The 16K MAC table supports mid-scale networks, and VLAN support enables basic traffic segmentation without management overhead. Dual Gigabit uplinks allow redundancy and higher-bandwidth core connections. Industrial certifications and comprehensive surge protection make this switch suitable for mission-critical security infrastructure where downtime is unacceptable.
