Features:
AI
Frame Rate:
30 fps
Sensor Type:
Approx. 1/2.8 type CMOS image sensor
Minimum Illumination:
Color : 0.015 lx (50IRE, F1.6, 1/30s); Color : 0.001 lx (50IRE, F1.6, 16/30s); BW : 0.006 lx (50IRE, F1.6, 1/30s); BW : 0.0004 lx (50IRE, F1.6, 16/30s)
White Balance:
ATW1 / ATW2 / AWC
Shutter Speed:
[60 fps Mode] 1/60 Fix to 1/10000 Fix, [30 fps/15 fps mode] 1/30 Fix to 1/10000 Fix; [50 fps Mode] 1/50 Fix to 1/10000 Fix, [25 fps/12.5 fps mode] 1/25 Fix to 1/10000 Fix
Intelligent Auto:
On / Off
Super Dynamic:
On / Off, the level can be set in the range of 0 to 31.
Dynamic Range:
Max.144 dB (Super Dynamic : On, Level 31)
Adaptive Black Stretch:
The level can be set in the range of 0 to 255.
Back light compensation / High light compensation:
BLC (Back light compensation) / HLC (High light compensation) / Off; The level can be set in the range of 0 to 31 (only when Super dynamic / Intelligent Auto : Off)
Fog compensation:
On / Off, The level can be set in the range of 0 to 8; (only when Intelligent auto / auto contrast adjust : Off)
Maximum gain (AGC:
The level can be set in the range of 0 to 11.
Color/BW (ICR:
Off / On / Auto1 / Auto2 / Auto3 (SCC)
Digital Noise Reduction:
The level can be set in the range of 0 to 255.
Video Motion Detection (VMD:
On / Off, 4 areas available
Scene Change Detection (SCD:
On / Off, 1 areas available
Audio Detection:
On / Off
AI Sound Classification:
-
AI Analytics:
-
Privacy Zone:
On / Off, Up to 32 zones available
VIQS:
On / Off, Up to 8 zones available
Image Stabilizer:
On / Off (Built-in gyro sensor)
Camera Title (OSD:
On / Off, Up to 40 characters (alphanumeric characters, marks)
Focus Adjustment:
Auto focus
Optical Zoom:
10x (Motorized zoom / Motorized Focus)
Extra zoom:
Max. 15x (10 to 15x : When resolution is 1280 x 720)
Focal Length:
4.7 - 47 mm {3/16 inches - 1-27/32 inches}
Angular Field of View:
[16 : 9 mode]; Horizontal : 6.7° (TELE) – 62° (WIDE), Vertical : 3.8° (TELE) – 37° (WIDE); [ 4 : 3 mode]; Horizontal : 5.1° (TELE) - 48° (WIDE), Vertical : 3.8° (TELE) - 37° (WIDE)
Maximum Aperture Ratio:
1 : 1.6 (WIDE) – 1 : 3.0 (TELE)
Focus Range:
1.5 m {59-1/16 inches} – ∞
Detect (25ppm / 8ppf:
Wide: 64.2m / 210.5 ft, Tele: 656.0 m / 2152.3 ft
Observe (62.5ppm / 19ppf:
Wide: 25.7 m / 84.2 ft, Tele: 262.4 m / 860.9 ft
Recognize (125ppm / 38ppf:
Wide: 12.8 m / 42.1 ft, Tele: 131.2 m / 430.5 ft
Identify (250ppm / 76ppf:
Wide: 6.4m / 21.1 ft, Tele: 65.6 m / 215.2 ft
System on Chip (SoC:
Ambarella CV25M
Adjusting Angle:
Horizontal : 360° Endless Panning, Vertical : -15° to +195°, Yaw : 0°
Panning Range:
360° Endless Panning
Panning Speed:
Manual: Approx. 0.065°/s – 150°/s, Preset: Up to approx. 500°/s
Tilting Range:
Operational -15 – +195°
Tilting Speed:
Manual: Approx. 0.065°/s –150°/s; Preset: Up to approx. 500°/s (PoE+), Up to approx. 350°/s (DC12 V PoE)
Preset Positions:
256 positions
Auto Mode:
Auto pan/ Preset sequence/ Patrol
Self Return:
10 s/ 20 s/ 30 s/ 1 min/ 2 min/ 3 min/ 5 min/ 10 min/ 20 min/ 30 min/ 60 min
Camera Control:
Brightness, AUX On / Off
Audio Support:
Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High; Audio Output : On / Off Volume adjustment : Low / Middle / High
GUI / Setup Menu Language:
English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese
Browser:
Microsoft Edge, Firefox, Google Chrome
Network IF:
10 Base-T / 100 Base-TX, RJ45 connector
Resolution H.265/ H.264 JPEG (MJPEG:
[16 : 9 mode (60 fps mode)], [16 : 9 mode (30 fps mode)],; [16 : 9 mode (50 fps mode)], [16 : 9 mode (25 fps mode)]; 1920x1080, 1280x720, 640x360, 320x180; [4 : 3 mode (30 fps mode)], [4 : 3 mode (25 fps mode)]; 1280x960, VGA, QVGA; [4 : 3 mode (15 f
H.265/H.264:
[Transmission Mode]; Constant bit rate / VBR / Frame rate / Best effort; [Transmission Type]; Unicast port (AUTO) / Unicast port (MANUAL) / Multicast
JPEG:
[Image Quality]; 10 steps
Smart Coding:
GOP (Group of pictures) control:; Off/ Low (Variable GOP 1s-8s)/ Mid (Variable GOP 4s-16s)/; Advanced(Fixed GOP 60s w/1s key-frame)/; Frame rate control (Variable GOP 4s-16s with frame rate control); *Advanced and Frame rate control are only availabl
Audio Compression:
G.726 (ADPCM) : 16 kbps / 32 kbps; G.711 : 64 kbps; AAC-LC : 64 kbps / 96 kbps / 128 kbps
Audio Transmission Mode:
Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex)
Supported Protocol:
IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, SFTP, MQTT, LLDP; IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, NMPv1/v2/v3
No. of Simultaneous Users:
Up to 14 users (Depends on network conditions)
Secure:
FIPS 140-2 level 3 Certified Secure Element (NXP® EdgeLock® SE050F), Device Certificate GlobalSign® pre-installed,; User authentication, Host authentication, HTTPS, 802.1X Support, Data encryption
SDXC/SDHC/SD Memory Card (Option:
H.265 / H.264 recording :; Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure; JPEG recording :; Manual REC / Alarm REC (Pre/Post) / Backup upon network failure; Compatible SDXC/SDHC/SD Memory Card :; microSDXC memory card
Mobile Terminal Compatibility:
iPad, iPhone (iOS 8.0 or later),; Android™ terminals
ONVIF® Profile:
G / S / T
Alarm Source:
3 terminals input, VMD alarm, Command alarm,; Audio detection alarm
Alarm Actions:
SDXC/SDHC/SD memory recording, E-mail notification,; HTTP alarm notification Indication on browser, TCP alarm notification output
Audio Input:
ø3.5 mm stereo mini jack; For microphone input : Recommended applicable microphone : Plug-in power type; (Sensitivity of microphone : –51 dB to –38 dB (0 dB=1 V/Pa, 1 kHz)); Input impedance : Approx. 2 kΩ (unbalanced); Supply voltage : 2.5 V ±0.5 V;
Audio Output:
ø3.5 mm stereo mini jack (stereo output); Output impedance : Approx. 600 Ω (unbalanced); Output level : –20 dBV
External I/O Terminals:
ALARM IN 1 (Alarm input 1/ Black & white input/ Auto time adjustment input) (x1); ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1), ALARM IN 3 (Alarm input 3/ AUX OUT) (x1)
Safety:
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1),; CE, IEC62368-1
EMC:
FCC (Part15 ClassA), ICES-003 Issue 7 ClassA,; EN55032 ClassA, EN55035
Power Source and Power Consumption:
DC12 V, PoE (IEEE802.3af), PoE+ (IEEE802.3at); DC12 V: 1.3 A / Approx.15.6 W; PoE DC 48 V: 270 mA / Approx.12.95 W (Class 0 device); PoE+ DC 54 V: 340 mA / Approx18.4 W(Class 4 device)
Ambient Operating Temperature:
-30 °C to +55 °C (-22 °F to +131 °F); (Power On range : -20 °C to +55 °C {-4 °F to +131 °F}); Maximum temperature according to NEMA TS2(2.2.7) : 74 °C(165 °F)
Ambient Operating Humidity:
10 to 100 % (no condensation)
Anti-Condensation System:
Temish element
Water and Dust Resistance:
IP66, IEC60529 measuring standard compatible,; Type 4X(UL50E), NEMA 4X compliant
Shock Resistance:
IK10 (IEC 62262)
Wind Resistance:
Up to 40 m/s {approx. 89 mph}
Other standard support:
NEMA TS2(2.2.7-2.2.9)
Dimensions:
ø165 mm x 139 mm (H) {ø6-1/2 inches x 5-15/32 inches (H)}
Mass (Approx:
Approx. 1.6 kg {3.53 lbs.}
Finish:
Main body : Aluminum die cast, Black polycarbonate resin, i-PRO white; Outer fixing screws : Stainless steel (Corrosion-resistant treatment); Dome section : Polycarbonate resin, Clear
Product Type:
Dome
Connectivity:
Wired
IP Rating:
IP66
Night Vision:
IR
Power Type:
PoE+
PoE Class:
0
Form Factor:
Dome
Vandal Rating:
IK10
Compatibility:
ONVIF
Resolution:
2MP
Video Compression:
H.265, H.264, MJPEG
Lens Focal Length:
4.7-47mm
IR Distance:
1.5m
Built-in IR:
Yes
Day/Night:
Yes
Storage Support:
microSD
Outdoor Ready:
Yes
Signed Firmware:
Yes
HTTPS Encryption:
Yes
OS:
Android
Image Stabilization:
Yes
