Features:
AI
Frame Rate:
High
Sensor Type:
1/1.2" Progressive Scan CMOS
Max. Resolution:
3840 × 2160
Min. Illumination:
Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time:
1/3 s to 1/100,000 s
Angle Adjustment:
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Day & Night:
24/7 color imaging
Focal Length & FOV:
2.8 mm, horizontal FOV 102°, vertical FOV 52°, diagonal FOV 124°;4 mm, horizontal FOV 88°, vertical FOV 47°, diagonal FOV 104°;6 mm: horizontal FOV 54°, vertical FOV 30°, diagonal FOV 62°
Lens Type:
Fixed focal lens, 2.8, 4, 6 mm optional
Iris Type:
Fixed
Aperture:
F1.0
Lens Mount:
M mount
Depth Of Field:
2.8 mm: 4.5 m to ∞;4 mm: 7 m to ∞;6 mm: 13 m to ∞
DORI:
2.8 mm: D: 96 m, O: 38 m, R: 19 m, I: 9 m;4 mm: D: 102 m, O: 40 m, R: 20 m, I: 10 m;6 mm, D: 167 m, O: 66 m, R: 33 m, I: 16 m
Supplement Light Type:
White Light
Supplement Light Range:
60 m
Smart Supplement Light:
Yes
Main Stream:
50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720);60 Hz: 24 fps (3840 × 2160);30 fps (3200 x 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream:
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360);60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream:
50 Hz: 10 fps (1920 x 1080, 1280 × 720, 640 × 480, 640 × 360);60 Hz: 10 fps (1920 x 1080, 1280 × 720, 640 × 480, 640 × 360)
Video Compression:
Main stream: H.265/H.264/H.264+/H.265+;Sub-stream: H.265/H.264/MJPEG;Third stream: H.265/H.264
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR/VBR
Scalable Video Coding (SVC:
Yes
Region Of Interest (ROI:
1 fixed region for main stream and sub-stream
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
Simultaneous Live View:
Up to 6 channels
API:
Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK
User/Host:
Up to 32 users. 3 user levels: administrator, operator and user
Security:
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage:
NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Plug-in required live view: IE 10, IE 11;Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+;Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image Parameters Switch:
Yes
Image Settings:
Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch:
Day, Night, Auto, Schedule
Wide Dynamic Range (WDR:
130 dB
SNR:
≥ 52 dB
Image Enhancement:
BLC, HLC, 3D DNR
Privacy Mask:
4 regions of privacy mask
Ethernet Interface:
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage:
Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 512 GB
Reset Key:
Yes
Built-In Microphone:
Yes
Built-In Speaker:
2 W, 10 cm: 97 dB
Audio Support:
1 input (line in), max. input amplitude: 3.3 Vpp, input impedance:4.7 KΩ, interface type: non-equilibrium;1 output (line out), max.output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Alarm:
1 input, 1 output (max. 24 VDC, 1 A)
Basic Event:
Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event:
Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggering by specified target types (human and vehicle)), scene change detection
Linkage:
Upload to NAS/memory card/FTP, notify surveillance center, trigger record, trigger capture, send email
Face Capture:
Yes
Power Type:
12 VDC ± 25%, 0.84 A, max. 11.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection;PoE: 802.3af, Class 3, 36 V to 57 V, 0.32 A to 0.21 A
Material:
Front cover: metal, body: metal, bracket: metal
Dimension:
289.9 mm × 93.5 mm × 91.2 mm (11.4" × 3.7" × 3.6")
Package Dimension:
386 × 156 × 155 mm (15.2" × 6.1" × 6.1")
Weight:
Approx. 1255 g (2.6 lb.)
With Package Weight:
Approx. 1769 g (3.7 lb.)
Storage Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language:
33 languages;English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditiona
General Function:
Anti-flicker, heartbeat, password reset via e-mail, pixel counter
EMC:
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 7);KC (KN32: 2015, KN35: 2015)
Safety:
UL (UL 62368-1); CB (IEC 62368-1:2014+A11);CE-LVD (EN 62368-1:2014/A11:2017)
Environment Rating:
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection:
IP67 (IEC 60529-2013)
Product Type:
Bullet
Connectivity:
Wired
IP Rating:
IP67
Resolution:
8MP
Night Vision:
Color
