Features:
AcuSense
Frame Rate:
30fps
Sensor Type:
1/3" Progressive Scan CMOS
Min. Illumination:
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Time:
1/3 s to 1/100,000 s
Day & Night:
IR cut filter
Angle Adjustment:
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Max. Resolution:
2688 × 1520
Focal Length & FOV:
2.8 to 12 mm, horizontal FOV 95.8° to 29.2°, vertical FOV 50.6° to 16.4°, diagonal FOV 114.6° to 33.4°
Aperture:
F1.6
Lens Mount:
Ø14
Lens Type:
Varifocal lens, motorized lens, 2.8 to 12 mm
Iris Type:
Fixed
DORI:
2.8 to 12 mm: D: 64 m to 200 m, O: 25.4 m to 79.4 m, R: 12.8 m to 40 m, I: 6.4 m to 20 m
Supplement Light Type:
IR
Supplement Light Range:
Up to 40 m
IR Wavelength:
850 nm
Smart Supplement Light:
Yes
Main Stream:
50 Hz: 25fps (2688 × 1520, 1920 × 1080, 1280 × 720);60 Hz: 30fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream:
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360);60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream:
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360);60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
Video Compression:
Main stream: H.265/H.264/H.264+/H.265+;Sub-stream: H.265/H.264/MJPEG;Third stream: H.265/H.264
Video Bit Rate:
32 Kbps to 8 Mbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR/VBR
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
1 fixed region for main stream and sub-stream
Environment Noise Filtering:
Yes
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate:
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Simultaneous Live View:
Up to 6 channels
API:
Open Network Video Interface (Profile S, Profile G), ISAPI, SDK
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket, WebSockets
User/Host:
Up to 32 users;3 user levels: administrator, operator, and user
Security:
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage:
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
SNR:
≥ 52 dB
Privacy Mask:
4 programmable polygon privacy masks
Day/Night Switch:
Day, Night, Auto, Schedule
Image Enhancement:
BLC, HLC, 3D DNR
Image Parameters Switch:
Yes
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Wide Dynamic Range (WDR:
120 dB
Audio Support:
1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium;1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type:
Alarm:
1 input, 1 output (max. 12 VDC, 30 mA)
On-Board Storage:
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Reset Key:
Yes
Ethernet Interface:
1 RJ45 10 M/100 M self-adaptive Ethernet port
Basic Event:
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Smart Event:
Face detection
Linkage:
Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture
Perimeter Protection:
Line crossing, intrusion;Support alarm triggering by specified target types (human and vehicle)
General Function:
Heartbeat, mirror, password reset via email, pixel counter, anti-banding
Storage Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Material:
Aluminum alloy body
Dimension:
Ø138.3 mm × 126 mm (Ø5.5" × 5.0")
Package Dimension:
216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6")
Weight:
Approx. 830 g (1.8 lb.)
With Package Weight:
Approx. 1115 g (2.5 lb.)
Power Type:
12 VDC ± 25%, 0.92 A, max. 11 W, Ø5.5 mm coaxial power plug, reverse polarity protection;PoE: IEEE 802.3af, Class 3, 36 V to 57 V, 0.35 A to 0.22 A, max. 12.5 W
Language:
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Tradition
EMC:
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
Safety:
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
Environment Rating:
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection:
IP67 (IEC 60529-2013), IK10 (IEC 62262: 2002)
Product Type:
Turret
Connectivity:
Wired
IP Rating:
IP67
Resolution:
4MP
Night Vision:
IR
