Features:
IR
Frame Rate:
30 fps
Sensor Type:
1/1.8" progressive scan CMOS
Max. Resolution:
3840 × 2160
Min. Illumination:
Color: 0.005 Lux @ (F1.5, AGC ON), B/W: 0.001 Lux@(F1.5, AGC ON), 0 Lux with IR
Shutter Speed:
1/1 s to 1/30000 s
Day & Night:
IR cut filter
Zoom:
25x optical, 16x digital
Slow Shutter:
Yes
DORI:
Detect (25px/m): 2046.9 m;Observe (63px/m): 812.3 m;Recognize (125px/m): 409.4 m;Identify (250px/m): 204.7 m
Focal Length:
5.9 mm to 147.5 mm
Field of View:
Horizontal field of view: 50.8° to 2.6° (wide-tele), Vertical field of view: 29.4° to 1.5° (wide-tele), Diagonal field of view:57.4° to 3° (wide-tele)
Focus:
Auto,semi-auto,manual
Aperture:
Max. F1.5
Zoom Speed:
Approx. 4.8 s
Supplement Light Type:
IR
Supplement Light Range:
IR Distance: up to 200 m
Movement Range (Pan:
360°
Movement Range (Tilt:
-15° to 90° (auto flip)
Pan Speed:
Pan speed: configurable from 0.1° to 160°/s; preset speed: 240°/s
Tilt Speed:
Tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s
Proportional Pan:
Yes
Presets:
300
Preset Freezing:
Yes
Patrol Scan:
8 patrols, up to 32 presets for each patrol
Pattern Scan:
4 pattern scans
Park Action:
Preset, pattern scan, auto scan, tilt scan, random scan, frame scan, panorama scan
3D Positioning:
Yes
PTZ Status Display:
Yes
Scheduled Task:
Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output
Power-Off Memory:
Yes
Main Stream:
50 Hz: 25 fps (3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720); 60 Hz: 24 fps (3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream:
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288); 60 Hz: 24 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream:
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288); 60 Hz: 24 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264;Sub-stream: H.265/H.264/MJPEG;Third stream: H.265/H.264/MJPEG
Video Bit Rate:
32 kbps to 16384 kbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
8 fixed regions for each stream
Audio Compression:
G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, AAC, PCM
Audio Bit Rate:
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps (MP2L2)/16-64 Kbps (AAC)
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/48 kHz
Environment Noise Filtering:
Yes
Protocols:
IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Simultaneous Live View:
Up to 20 channels
API:
Open Network Video Interface (Version 19.12, Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
User/Host:
Up to 32 users, 3 user levels: administrator, operator, and user
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security aud
Network Storage:
NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Client:
iVMS-4200, HikCentral Pro, Hik-Connect
Web Browser:
IE11, Chrome 57+, Firefox 52+, Safari 11+
Image Settings:
Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
Day/Night Switch:
Day, Night, Auto, Schedule
Wide Dynamic Range (WDR:
120 dB
SNR:
> 52 dB
Defog:
Digital defog
Image Stabilization:
EIS
Image Enhancement:
BLC, HLC, 3D DNR
Privacy Mask:
24 programmable polygon privacy masks, mask color or mosaic configurable
Regional Focus:
Yes
Regional Exposure:
Yes
Ethernet Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
On-Board Storage:
Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
Built-In Speaker:
1 built-in speaker with effective distance reaching max. 30 meters
Audio Support:
1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 kΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
Alarm:
2 inputs, 1 output
Reset:
Yes
Basic Event:
Motion detection, video tampering alarm, exception, alarm input and output
Smart Event:
Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection
Linkage:
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing, and PTZ actions (such as preset, patrol scan, pattern scan)
Smart Tracking:
Manual tracking, auto-tracking
Face Capture:
Detects up to 5 faces simultaneously.;Supports detecting, capturing, grading, selecting of face in motion, and output the best face picture of the face
Perimeter Protection:
Line crossing, intrusion, region entrance, region exiting;Support alarm triggering by specified target types (human and vehicle)
Power Type:
24 VAC, max. 42 W (including max. 18 W for IR and max. 10 W for heater); Hi-PoE
Dimension:
Ø 220 mm × 363.3 mm (Ø 8.66" × 13.91")
Weight:
Approx. 5 kg (11.03 lb.)
Material:
ADC12
Operating Condition:
-30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing)
Demist:
Yes
EMC:
UL (UL 62368-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 62368-1:2014+A11:2017); BIS (IS 13252 (Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
Safety:
UL (UL 62368-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 62368-1:2014+A11:2017); BIS (IS 13252 (Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
Environment Rating:
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection:
IP66 (IEC 60529-2013), IK10 (excluding glass window), TVS 6000V lightning protection, surge protection and voltage transient protection
Product Type:
Dome
Connectivity:
Wired
Night Vision:
IR
Form Factor:
Dome
IP Rating:
IP66
Vandal Rating:
IK10
Max Channels:
20
Resolution:
8MP
Day/Night:
Yes
Optical Zoom:
25x
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
WDR:
WDR
Max Resolution:
3840x2160
Image Sensor Size:
1/1.8" progressive
scan CMOS
Horizontal Fov:
50.8°
Vertical Fov:
29.4°
