Hanwha XNV-6083R 2MP Vandal-Resistant PTZ Dome

Hanwha XNV-6083R 2MP Vandal-Resistant PTZ Outdoor Dome IP CameraThe Hanwha XNV-6083R is a professional-grade 2MP outdoor dome camera engineered for hi…

Add to cart for sale price
$2,300.00
$1,384.99
Ships same business day
In stock

Quantity:

Adding to cart… The item has been added
Compatibility guidance available for your deployment
Certified experts for pre and post-sales support
Authorized sourcing and documentation support
Shipping and lead-time confirmation before install
Bryan

Talk to Bryan

200+ hrs training • U.S - based

Certified Expert • 877-277-7147

Live Chat Call

Hanwha XNV-6083R 2MP Vandal-Resistant PTZ Dome

$2,300.00
$1,384.99
Add to Cart

Your recommended setup

Review items below — quantities update pricing automatically.

Item Qty Status Price
Optional Add-Ons recommended
Services optional

Bundle Summary

Bundle Subtotal: $0.00
Optional Add-Ons: $0.00
Services: $0.00
Total: $0.00

Overview

SKU: QNP-6320
UPC: 8801089204479
Condition: New
Availability: Usually ships in 24 hours
Warranty 3-year warranty
Description

Hanwha XNV-6083R 2MP Vandal-Resistant PTZ Outdoor Dome IP Camera

The Hanwha XNV-6083R is a professional-grade 2MP outdoor dome camera engineered for high-security applications requiring 24/7 surveillance in challenging environments. Combining robust vandal-resistant construction with advanced pan-tilt-zoom capabilities and intelligent analytics, this camera delivers comprehensive situational awareness for critical infrastructure, transportation hubs, and large outdoor areas.

Key Features

  • 2MP (1920x1080) resolution with 1/2.8" CMOS imaging sensor
  • 32x optical zoom varifocal lens (4.44–142.6mm) with 1024x total digital zoom
  • 360° endless pan with 700°/sec preset speed; 105° tilt range with 300°/sec preset speed
  • Built-in IR illumination with 50-meter detection range; 0.005 Lux minimum illumination in B&W mode
  • IP67-rated vandal-resistant dome with outdoor-grade durability (-10°C to +55°C operating range)
  • 120dB wide dynamic range (WDR) with HLC, BLC, and SSDR for high-contrast scenes
  • H.265/H.264/MJPEG video compression at up to 60fps; H.265 delivers superior bandwidth efficiency
  • Advanced analytics: directional detection, motion detection, virtual line crossing, tampering alerts, and audio detection
  • Auto-tracking capability for moving subjects
  • Built-in gyro sensor for digital image stabilization and defog support
  • PoE+ (IEEE 802.3at Class 4) powered; maximum 14.5W consumption
  • MicroSD/SDHC/SDXC edge storage up to 256GB

Technical Specifications

The XNV-6083R captures exceptional detail across varied lighting conditions. At 0.05 Lux in color mode and 0.005 Lux in B&W, the camera operates effectively in near-complete darkness. The F1.6 wide aperture and motorized iris control enable precise exposure management. Pan and tilt presets achieve ±0.2° accuracy, supporting up to 300 preset positions for repeatable framing in multi-camera deployments.

Networking capabilities include ONVIF Profile S/G/T compliance, SUNAPI HTTP API access, and support for IPv4/IPv6, RTSP, HTTPS, and SRTP. Security features encompass 802.1X authentication, digest authentication, brute-force attack prevention, and firmware encryption. Alarm inputs/outputs (4 in, 2 out) enable integration with external systems. The camera supports 10 concurrent streaming profiles and multicast delivery, accommodating large-scale surveillance networks.

Applications

Ideal for perimeter security, parking facilities, traffic monitoring, critical infrastructure protection, and large open areas requiring extended zoom coverage and proven vandal resistance.

Karl Wilson
Karl Wilson

The XNV-6083R excels in mid-to-large area coverage where PTZ capability and optical zoom justify higher upfront costs. The 32x optical zoom—particularly the 1921m detection range at telephoto—enables single-camera solutions that would require multiple fixed cameras. WDR performance and low-light sensitivity are enterprise-class; the 120dB range and 0.005 Lux rating handle backlit entrances, reflective surfaces, and dusk/dawn transitions seamlessly.

Integration strength is substantial: ONVIF compliance ensures VMS platform flexibility, while analytics (virtual line, directional detection, auto-track) reduce false alerts and enable proactive alerting without external GPU processing. The IP67 rating and outdoor temperature range (-10°C to +55°C) confirm durability; however, very high-temperature environments (above +55°C) require passive cooling via housing. PoE+ at 12W typical offers efficient single-cable power and data delivery. Edge storage via microSD is valuable for local failover, though continuous high-bitrate recording (especially H.264) requires careful SD card selection and NAS backup planning.

Product Documentation

📄 Download Product Datasheet (PDF)

Expert Analysis
Specifications
Frame Rate: 60fps
Imaging Device: 1/2.8" CMOS
Resolution: 1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
Max. Framerate: H.265/H.264: Max. 60fps/50fps(60Hz/50Hz); MJPEG: Max. 30fps/25fps(60Hz/50Hz)
Min. Illumination: Color: 0.05Lux(F1.6, 1/30sec, 30IRE); BW: 0.005Lux(F1.6, 1/30sec, 30IRE)
Focal Length (Zoom Ratio: 4.44~142.6mm(32x) zoom (digital 32x, total 1024x zoom)
Max. Aperture Ratio: F1.6(Wide)~F4.4(Tele)
Angular Field of View: H: 64.66°(Wide)~2.29°(Tele); V: 38.08°(Wide)~1.30°(Tele)
Min. Object Distance: Wide: 1.5m(4.92ft) / Tele: 2m(6.56ft)
Focus Control: Oneshot AF, Focus save
Lens Type: DC auto iris
Pan Range: 360° Endless
Pan Speed: Preset: 700°/sec, Manual: 0.024°/sec~200°/sec
Tilt Range: 105°(90°~-15°)
Tilt Speed: Preset: 300°/sec, Manual: 0.024°/sec~200°/sec
Sequence: Preset(300ea), Swing, Group(6ea), Trace, Tour, Auto Run, Schedule
Preset Accuracy: ±0.2°
Camera Title: Displayed up to 85 characters
Direction Indicator: Support
Day & Night: Auto(ICR)
Backlight Compensation: BLC, HLC, WDR, SSDR
Wide Dynamic Range: 120dB
Digital Noise Reduction: SSNRⅤ
Digital Image Stabilization: Support(built-in gyro sensor)
Defog: Support
Motion Detection: 8ea, 8point polygonal zones
Privacy Masking: 32ea, 4point quadrangle zones; - Color: Grey/Green/Red/Blue/Black/White; - Solid/Mosaic
Gain Control: Low / Middle / High
White Balance: ATW / AWC / Manual / Indoor / Outdoor / Mercury / Sodium
Electronic Shutter Speed: Minimum / Maximum / Anti flicker (2~1/12,000sec)
Video Rotation: Flip, Mirror
Analytics: Analytics events; - Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line, Audio detection
Alarm Inputs/Outputs: Input 4ea / Output 2ea
Alarm Triggers: Analytics, Network disconnect, Alarm input
Alarm Events: When alarm trigger occurred; - File upload(image) : e-mail/FTP; - Notification : e-mail; - Recording : SD/SDHC/SDXC or NAS recording at event triggers; - Alarm output; - Handover(PTZ preset, Send message by HTTP/HTTPS/TCP)
Audio In: Selectable(mic in/line in); Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
Audio Out: Line out, Max.output level: 1Vrms
Auto Tracking: Support
Ethernet: RJ-45(10/100BASE-T)
Video Compression: H.265/H.264: Main/High, MJPEG
Audio Compression: G.711 u-law /G.726 Selectable; G.726(ADPCM) 8KHz, G.711 8KHz; G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps; AAC-LC: 48Kbps at 16KHz
Smart Codec: Manual(5ea area), WiseStreamⅡ
Bitrate Control: H.264/H.265: CBR or VBR; MJPEG: VBR
Streaming: Unicast(20 users) / Multicast; Multiple streaming(Up to 10 profiles)
Protocol: IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast), NTCIP1205
Application Programming Interface: ONVIF Profile S/G/T; SUNAPI(HTTP API); Wisenet open platform
OS / Firmware Protect: Firmware encryption
User authentication: Digest Authentication, Privent brute-force attack
Network authentication: 802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
Secure Communication: HTTPS, SRTP, WSS(Websocket secure)
Access Control: IP address filtering
Data Protect: Authentication information encryption, ZIP compression encryption
Audit: User Access/System/Event log
Device ID: Device Certificate(Hanwha Techwin Root CA, pre-installed)
Webpage Language: English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Edge Storage: Micro SD/SDHC/SDXC 1slot Max. 256GB
RAM: 1GB RAM, 256MB Flash
Operating Temperature / Humidity: -10°C~+55°C(14°F~+131°F) / 0~95% RH(Non-condensing)
Storage Temperature / Humidity: -30°C~+60°C(-22°F~+140°F) / 0~95% RH
Input Voltage: PoE+(IEEE802.3at, Class4)
Power (Max: PoE+: Max 14.5W, typical 12W
Color / Material: White / Plastic
RAL Code: RAL9003
Product Dimensions / Weight: ø152x218mm(ø5.98x8.58"), 1700g(3.75 lb)
Hanging Mount (Dome: SBP-301HMW3
Ceiling Mount (Assy: SBP-300CMW, SBP-300CMW1/900CMW, SBP-150CMI/300CMI, SBP-300CMTW, SBP-300CMTS
Wall Mount: SBP-300WMW1, SBP-300WMW, SBP-250WMW, SBP-390WMW2
Pole Mount: SBP-300PMW2, SBP-156LMW1
In-ceiling Mount: SHP-1520FW
Parapet Mount: SBP-300LMW
Corner Mount: SBP-300KMW1
Housing (Box: SHP-3701H
Cabinet: SBP-300NBW
Other Compatible Models: SPB-PTZ6, SBP-115PFA
EMC: FCC 47 CFR 15 Subpart B Class A; IC Regulation ICES-003 Issue 7 Class A; CE/UKCA; - EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3; VCCI CISPR 32 Class A; RCM AS/NZS CISPR 32 Class A
Safety: UL 62368-1, CAN/CSA C22.2 NO. 62368-1
Environment Rating: IEC/EN 63000
Detect (25PPM/ 8PPF: Wide: 60.7m(199.1ft) / Tele: 1921.3m(6303.4ft)
Observe (63PPM/ 19PPF: Wide: 24.3m(79.6ft) / Tele: 768.5m(2521.4ft)
Recognize (125PPM/ 38PPF: Wide: 12.1m(39.8ft) / Tele: 384.3m(1260.7ft)
Identify (250PPM/ 76PPF: Wide: 6.1m(19.9ft) / Tele: 192.1m(630.3ft)
Product Type: Dome
Connectivity: Wired
IP Rating: IP67
Features: WDR
Night Vision: IR
Power Type: PoE+
PoE Class: 4
Form Factor: PTZ
Compatibility: ONVIF
IR Distance: 1.5m
Built-in IR: Yes
Day/Night: Yes
Storage Support: microSD
HTTPS Encryption: Yes
WDR: WDR
Weight Lbs: 3.75
