Features:
Defocus Detection
Frame Rate:
30fps
Imaging Device:
1/2.8" CMOS
Resolution:
3840x2160, 3328x1872, 3072x1728, 2592x1944, 2688x1520, 1920x1080, 1600x1200, 1280x1024,1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
Max. Framerate:
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz); MJPEG: Max. 30fps(@8MP Max. 5fps)
Min. Illumination:
Color: 0.03Lux(F1.6, 1/30sec, 30IRE); BW: 0.003Lux(F1.6, 1/30sec, 30IRE), 0Lux(IR LED on)
Video Out:
USB: Micro USB Type B, 1280x720 for installation
Focal Length (Zoom Ratio:
3.0mm fixed focal
Max. Aperture Ratio:
F1.6
Angular Field of View:
H: 108°/ V: 59°/ D: 127°
Min. Object Distance:
0.5m (1.64ft)
Focus Control:
Fixed
Lens Type:
Fixed IRIS
Mount Type:
M12
Pan / Tilt / Rotate Range:
0°~350° / -35°~70° / 0°~355°
Camera Title:
Displayed up to 85 characters
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, WDR, SSDR
Wide Dynamic Range:
120dB
Digital Noise Reduction:
SSNRⅤ, WiseNRⅡ(Based on AI engine)
Motion Detection:
8ea, 8point polygonal zones
Privacy Masking:
32ea, 4point quadrangle zones
Gain Control:
Low / Middle / High
White Balance:
ATW / AWC / Manual / Indoor / Outdoor
LDC:
Support
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (1/5~1/12,000sec)
Video Rotation:
Flip, Mirror, Hallway view(90°/270°)
Analytics:
Classified object type: Person/Vehicle; Attributes: Vehicle(Type:car/bus/truck/motorcycle/bicycle); Support DetectionShot; Analytics events based on AI engine; - Motion detection*, Object detection, Virtual line*(Crossing/Direction), Virtual area*(Lo
Business Intelligence:
Based on AI engine: People counting, Vehicle counting, Queue management, Heatmap
Alarm Triggers:
Analytics, Network disconnect
Alarm Events:
When alarm trigger occurred; - File upload(image) : e-mail/FTP; - Notification : e-mail; - Recording : SD/SDHC/SDXC or NAS recording at event triggers; - Handover(PTZ preset, Send message by HTTP/HTTPS/TCP)
IR Viewable Length:
20m(65.62ft)
IR Wavelength:
long-life 850 nm IR LED
Ethernet:
RJ-45(10/100BASE-T)
Video Compression:
H.265/H.264: Main/High, MJPEG
Smart Codec:
Manual(5ea area), WiseStreamⅢ(Based on AI engine)
Bitrate Control:
H.264/H.265: CBR or VBR; MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast; Multiple streaming(Up to 5 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP (TCP, UDP Unicast)
Application Programming Interface:
ONVIF Profile S/G/T/M; SUNAPI(HTTP API)
OS / Firmware Protect:
Secure boot, Signed firmware, Firmware encryption
User authentication:
Digest Authentication, Prevent brute-force attack
Network authentication:
802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
Secure Communication:
HTTPS, SRTP, WSS(Websocket secure)
Access Control:
Access control based on IP address
Data Protect:
Authentication information encryption, ZIP compression encryption
Audit:
User Access/System/Event log management
Device ID:
Device Certificate(Hanwha Private Root CA)
Secure Storage:
SDcard partition encrypt
Security Certificate:
Secure by default
Webpage Language:
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Edge Storage:
Micro SD/SDHC/SDXC 1slot 256GB
RAM:
2GB RAM, 1GB Flash
Operating Temperature / Humidity:
-40°C~+55°C(-40°F~+131°F) / 0~95% RH; * Start up should be done at above -30°C; Humidity control /w Air vapor control
Storage Temperature / Humidity:
-50°C~+60°C(-58°F~+140°F) / 0~95% RH
Certification:
IP66, IK10, NEMA4X
Input Voltage:
PoE(IEEE802.3af, Class3)
Power (Max:
PoE: Max 8.5W, typical 4.9W
Color / Material:
White / Aluminum; Bubble : Hard-coated dome
RAL Code:
RAL9003
Product Dimensions / Weight:
ø110x77mm(ø4.33x3.03"), 522g(1.15 lb)
Compatible Conduit hole / Gangbox:
SBD-110GP1 : Single, Double, 4" Octagon (Sold seperately)
Hanging Mount (Dome:
SBP-120HMW
Backbox:
SBV-140BW
EMC:
FCC 47 CFR 15 Subpart B Class A; ICES-3(A)/NMB-3(A); CE/UKCA; - EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3; VCCI CISPR 32 Class A; RCM AS/NZS CISPR 32 Class A; KS C 9832 Class A, KS C 9835
Safety:
UL 62368-1, CAN/CSA C22.2 NO. 62368-1; IEC/EN 62471
Environment Rating:
IEC/EN 63000; IEC/EN 60529 IP66, IEC/EN 62262 IK10
Detect (25PPM/ 8PPF:
55.8m(183.07ft)
Observe (63PPM/ 19PPF:
22.5m(73.23ft)
Recognize (125PPM/ 38PPF:
11.2m(36.61ft)
Identify (250PPM/ 76PPF:
5.6m(18.31ft)
Product Type:
Dome
Connectivity:
Wired
IP Rating:
IP66
Night Vision:
IR
Power Type:
PoE
PoE Class:
3
Form Factor:
Dome
Vandal Rating:
IK10
Compatibility:
ONVIF
IR Distance:
0.5m
Built-in IR:
Yes
Day/Night:
Yes
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
WDR:
WDR
Weight Lbs:
1.15
