Frame Rate:
60fps
Imaging Device:
1/2.8" CMOS
Resolution:
1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
Max. Framerate:
H.265/H.264: Max. 60fps/50fps(60Hz/50Hz); MJPEG: Max. 30fps/25fps(60Hz/50Hz)
Min. Illumination:
Color: 0.05Lux(F1.6, 1/30sec, 30IRE); BW: 0.005Lux(F1.6, 1/30sec, 30IRE), 0Lux(IR LED On)
Focal Length (Zoom Ratio:
4.44~111mm(25x) zoom (digital 32x, total 800x zoom)
Max. Aperture Ratio:
F1.6(Wide)~F3.9(Tele)
Angular Field of View:
H: 64.66°(Wide)~2.99°(Tele); V: 38.08°(Wide)~1.68°(Tele)
Min. Object Distance:
Wide: 1.5m(4.92ft) / Tele: 2m(6.56ft)
Focus Control:
Oneshot AF, Focus save
Lens Type:
DC auto iris
Pan Range:
360° Endless
Pan Speed:
Preset: 700°/sec, Manual: 0.024°/sec~250°/sec
Tilt Range:
110°(90°~-20°)
Tilt Speed:
Preset: 300°/sec, Manual: 0.024°/sec~250°/sec
Sequence:
Preset(300ea), Swing, Group(6ea), Trace, Tour, Auto Run, Schedule
Preset Accuracy:
±0.2°
Camera Title:
Displayed up to 85 characters
Direction Indicator:
Support
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, HLC, WDR, SSDR
Wide Dynamic Range:
120dB
Digital Noise Reduction:
SSNRⅤ
Digital Image Stabilization:
Support(built-in gyro sensor)
Defog:
Support
Motion Detection:
8ea, 8point polygonal zones
Privacy Masking:
32ea, 4point quadrangle zones; - Color: Grey/Green/Red/Blue/Black/White; - Solid/Mosaic
Gain Control:
Low / Middle / High
White Balance:
ATW / AWC / Manual / Indoor / Outdoor / Mercury / Sodium
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (2~1/12,000sec)
Video Rotation:
Flip, Mirror
Analytics:
Analytics events; - Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line; * Audio detection(Via optional I/O box SPM-4210)
Alarm Triggers:
Analytics, Network disconnect; * Alarm input((Via optional I/O box SPM-4210)
Alarm Events:
When alarm trigger occurred; - File upload(image) : e-mail/FTP; - Notification : e-mail; - Recording : SD/SDHC/SDXC or NAS recording at event triggers; - Alarm output; - Handover(PTZ preset, Send message by HTTP/HTTPS/TCP); * Alarm output / Audio cli
Light Type:
IR LED (850nm)
IR Viewable Length:
100m(328.08ft)
Auto Tracking:
Support
Ethernet:
Metal shielded RJ-45(10/100BASE-T)
Video Compression:
H.265/H.264: Main/High, MJPEG
Smart Codec:
Manual(5ea area), WiseStreamⅡ
Bitrate Control:
H.264/H.265: CBR or VBR; MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast; Multiple streaming(Up to 10 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast), NTCIP1205
Application Programming Interface:
ONVIF Profile S/G/T; SUNAPI(HTTP API); Wisenet open platform
OS / Firmware Protect:
Firmware encryption
User authentication:
Digest Authentication, Privent brute-force attack
Network authentication:
802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
Secure Communication:
HTTPS, SRTP, WSS(Websocket secure)
Access Control:
IP address filtering
Data Protect:
Authentication information encryption, ZIP compression encryption
Audit:
User Access/System/Event log
Device ID:
Device Certificate(Hanwha Techwin Root CA, pre-installed)
Webpage Language:
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Edge Storage:
Micro SD/SDHC/SDXC 1slot Max. 256GB
RAM:
1GB RAM, 256MB Flash
Storage Temperature / Humidity:
-50°C~+60°C(-58°F~+140°F) / 0~95% RH
Certification:
IP66, IK10, NEMA4X
Input Voltage:
PoE+(IEEE802.3at, Class4)
Power (Max:
PoE+: Max. 25.5W, typical 14.7W
Color / Material:
Body : White / Aluminum; Head : Black / Polycarbontate; Hard-coated dome
RAL Code:
RAL9003
Product Dimensions / Weight:
ø158x293.3mm(ø6.22x11.55"), 3100g(6.83lb)
Hanging Mount (Dome:
SBP-156HMW
Ceiling Mount (Assy:
SBP-156CMW, SBP-300CMTS, SBP-300CMW1/900CMW, SBP-150CMI/300CMI
Wall Mount:
SBP-156WMW, SBP-390WMW2
Pole Mount:
SBP-300PMW2
In-ceiling Mount:
SHP-1563FPW/FW
Parapet Mount:
SBP-156LMW, SBP-300LMW
Corner Mount:
SBP-156KMW, SBP-300KMW1
Cabinet:
SBP-300NBW
Other Compatible Models:
SPB-PTZ85W
EMC:
FCC 47 CFR 15 Subpart B Class A; IC Regulation ICES-003 Issue 7 Class A; CE/UKCA; - EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3; VCCI CISPR 32 Class A; RCM AS/NZS CISPR 32 Class A
Safety:
UL 62368-1, CAN/CSA C22.2 NO. 62368-1; IEC/EN 62471
Environment Rating:
IEC/EN 63000; IEC/EN 60529 IP66, IEC/EN 62262 IK10
Detect (25PPM/ 8PPF:
Wide: 60.7m(199.1ft) / Tele: 1471.3m(4827.2ft)
Observe (63PPM/ 19PPF:
Wide: 24.3m(79.6ft) / Tele: 588.5m(1930.9ft)
Recognize (125PPM/ 38PPF:
Wide: 12.1m(39.8ft) / Tele: 294.3m(965.4ft)
Identify (250PPM/ 76PPF:
Wide: 6.1m(19.9ft) / Tele: 147.1m(482.7ft)
Product Type:
Dome
Connectivity:
Wired
IP Rating:
IP66
Features:
WDR
Night Vision:
IR
Power Type:
PoE+
PoE Class:
4
Form Factor:
Dome
Vandal Rating:
IK10
Compatibility:
ONVIF
IR Distance:
1.5m
Built-in IR:
Yes
Day/Night:
Yes
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
WDR:
WDR
Weight Lbs:
6.83
