Vivotek HLG-60H-24 24VDC 60W Industrial Power Supply

Vivotek HLG-60H-24 24VDC 60W Industrial Power Supply

The Vivotek HLG-60H-24 is a robust industrial-grade power supply engineered for demanding IP surveillance and outdoor security applications. Delivering a regulated 24VDC at 60W with an exceptionally wide input range of 90–305VAC, this unit excels in environments with unstable or variable electrical standards. Its IP67 rating and extended operating temperature range of -40°C to 70°C make it ideal for harsh outdoor installations where reliability and longevity are critical.

Key Features

• Wide Input Range: Accepts 90–305VAC (47–63Hz), compatible with global electrical standards and varying supply conditions
• Stable DC Output: Delivers 24VDC at 2.5A (60W) with ±1.0% voltage tolerance and ±0.5% line/load regulation
• IP67 Sealed Enclosure: Fully protected against dust and water immersion up to 1 meter, suitable for outdoor mounting
• Extreme Temperature Rating: Operates reliably from -40°C to +80°C case temperature, ensuring year-round functionality
• Comprehensive Protections: Built-in overcurrent limiting (95–108%), short-circuit protection (hiccup mode), and overvoltage shutdown with automatic recovery
• High Efficiency: 89.5% typical efficiency reduces heat dissipation and power loss
• Low Ripple & Noise: Maximum 150mVp-p output ripple ensures clean power for sensitive surveillance equipment
• Adjustable Output (A/AB-Type): Optional voltage (22–27V) and current (1.5–2.5A) adjustment via built-in potentiometer

Technical Highlights

This power supply meets stringent international safety and EMC standards including UL8750, EN61347-1/2-13, GB19510, and EAC TP TC 004 certifications. Input-to-output isolation withstands 3.75KVAC, while isolation resistance exceeds 100MΩ at 500VDC. The unit's power factor exceeds 0.92 across all input ranges, with THD below 20% at specified load levels, ensuring compatibility with sensitive electrical infrastructure.

With a typical MTBF of 3,396.9K hours (Bellcore), the HLG-60H-24 demonstrates exceptional reliability for continuous-duty applications. Fast setup and rise times (500ms/80ms at 115–230VAC) and 16ms hold-up time protect connected devices during brief power interruptions. At 230VAC, up to 9 units can operate on a 16A Type B circuit breaker, or 16 units on a Type C breaker, enabling efficient multi-camera installations.

Applications

• Outdoor IP camera power distribution in harsh climates
• Remote surveillance systems in extreme temperature zones
• Industrial and transportation security infrastructure
• Multi-camera surveillance arrays requiring stable, protected power
• Installations requiring extended operational temperature ranges

Jerry Tildsen

The HLG-60H-24 is purpose-built for outdoor surveillance deployments where environmental stress and power instability are concerns. Its IP67 rating and wide input tolerance eliminate the need for intermediate conditioning equipment, reducing installation costs and failure points. The adjustable output and comprehensive fault protection—including hiccup-mode short-circuit recovery—make it suitable for both fixed camera installations and dynamic network expansions.

For integrators deploying multiple units, the high power factor and circuit breaker density enable substantial camera arrays on standard electrical circuits. The extended MTBF rating and international certifications reflect Vivotek's commitment to mission-critical surveillance reliability.
