Features:
AI
Frame Rate:
High
Sensor Type:
[Panoramic channel] 1/1.8" Progressive Scan CMOS, [PTZ channel] 1/1.8" Progressive Scan CMOS
Min. Illumination:
[PTZ channel] Color: 0.0005 Lux @ (F1.3, AGC ON), B/W: 0.0001 Lux @ (F1.3, AGC ON), 0 lux with IR,[Panoramic channel] Color: 0.0005 Lux @ (F1.4, AGC ON), B/W: 0.0001 Lux @ (F1.4, AGC ON), 0 Lux with light
Shutter Speed:
1 s to 1/30000 s
Slow Shutter:
Yes
Day & Night:
[Panoramic channel] Color, [PTZ channel] IR cut filter
Zoom:
[PTZ channel] 42 × optical, 16 × digital
Max. Resolution:
[Panoramic channel] 3632 × 1632, [PTZ channel] 2560 × 1440
Field of View:
[Panoramic channel] horizontal field of view: 190° ± 5°, vertical field of view: 80°±5°, [PTZ channel] horizontal field of view: 59° to 2°, vertical field of view: 34.2° to 11°, diagonal field of view: 67.1° to 2.3°
Focus:
Auto,semi-auto,manual
Zoom Speed:
[Panoramic channel] No, [PTZ channel] approx. 5.6 s
Focal Length:
[Panoramic channel] 2.8 mm, [PTZ channel] 6 to 252 mm
Aperture:
[Panoramic channel] F1.0, [PTZ channel] F1.3
Supplement Light Range:
[Panoramic channel] white light: up to 30 m, [PTZ channel] IR: up to 300 m
Smart Supplement Light:
Yes
Movement Range (Pan:
360° endless
Movement Range (Tilt:
[Panoramic channel] 12° to 24°, [PTZ channel] -20° to 90°
Pan Speed:
[PTZ channel] pan speed: configurable from 0.1° to 160°/s, preset speed: 240°/s
Tilt Speed:
[PTZ channel] tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s,[Panoramic channel] tilt speed configurable
Proportional Pan:
[Panoramic channel] No, [PTZ channel] Yes
Presets:
300
Patrol Scan:
8 patrols, up to 32 presets for each patrol
Pattern Scan:
4 pattern scans, record time over 10 minutes for each scan
Power-Off Memory:
Yes
Park Action:
Preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan
3D Positioning:
Yes
PTZ Status Display:
Yes
Preset Freezing:
Yes
Scheduled Task:
Preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan,dome reboot,dome adjust,aux output
Main Stream:
[PTZ channel] 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720), 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720),[Panoramic channel] 50 Hz: 25 fps (3680 × 1656，3632 × 1632), 60 Hz: 30 fps (3680 × 1656，3632 × 1632)
Sub-Stream:
[PTZ channel] 50 Hz: 25 fps (704 × 576，640 × 480，352 × 288), 60 Hz: 30 fps (704 × 576，640 × 480，352 × 288),[Panoramic channel] 50 Hz: 25 fps (1200 × 536、960x432), 60 Hz: 30 fps (1200 × 536、960x432)
Third Stream:
[PTZ channel] 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240),[Panoramic channel] No
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264/MJPEG
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Baseline profile,Main profile,High profile
H.265 Type:
Main profile
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
8 fixed regions for each stream
Audio Compression:
G.711,G.722.1,G.726,MP2L2,PCM,AAC-LC
Audio Bit Rate:
32 to 192 Kbps (MP2L2),16 to 64Kbps (AAC-LC)
Audio Sampling Rate:
8 kHz,16 kHz,32 kHz,48 kHz
Environment Noise Filtering:
Yes
API:
ISAPI,SDK,ISUP,ONVIF
Network Storage:
NAS (NFS, SMB/CIFS),auto network replenishment (ANR)
Protocols:
IPv4/IPv6,HTTP,HTTPS,802.1X,QoS,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP/IP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,FTP
Simultaneous Live View:
Up to 20 channels
User/Host:
Up to 32 users. 3 user levels: administrator, operator, and user
Security:
Password protection,complicated password,IP address filter,HTTPS encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5),host authentication (MAC address),watermark
Client:
iVMS-4200,HikCentral Pro,Hik-Connect
Web Browser:
IE 10+, Chrome 57+, Firefox 52+, Safari 12+
Wide Dynamic Range (WDR:
[Panoramic channel] 120 dB, [PTZ channel] 120 dB
Day/Night Switch:
Day,night,auto,schedule
Image Enhancement:
HLC,3D DNR
Privacy Mask:
[Panoramic channel] 8 programmable polygon privacy masks, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable
Defog:
Optical defog
Image Stabilization:
EIS (Built-in gyroscope to improve EIS performance)
Regional Exposure:
Yes
Regional Focus:
[Panoramic channel] No, [PTZ channel] Yes
Image Settings:
Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
Image Parameters Switch:
Yes
SNR:
≥ 52 dB
Satellite Positioning:
No
Gyroscope:
Yes
Compass:
No
Ethernet Interface:
1 RJ45 100M self-adaptive Ethernet port
On-Board Storage:
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Alarm:
7 input(s), 2 output(s)
Audio Support:
1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%, 1 output (line out), line level, output impedance: 600 Ω
RS-485:
1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset:
Yes
Basic Event:
[PTZ channel & panoramic channel] alarm input and output, exception,[PTZ channel] motion detection, video tampering alarm
Smart Event:
[Panoramic channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection,[PTZ channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection
Linkage:
[Panoramic channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing, [PTZ channel] Upload to FTP/NAS/memory card, notify surveillance center, send e
Smart Tracking:
[PTZ channel] yes
Smart Linkage:
Manual tracking, tracking takeover, linked tracking capture
Multi-Target-Type Detection:
[PTZ channel] Supports simultaneous detection and capture of human body and face
Perimeter Protection:
PTZ and Panoramic channel both support
General Function:
mirror,password protection
Power Type:
36 VDC ± 25%, max. 60 W, Hi-PoE,including max. 6 W for heater and max. 3 W for supplement light of panoramic channel, and max. 6 W for heater and max. 12 W for supplement light of PTZ channel
Operating Condition:
-40 °C to 70 °C (-40 °F to 158 °F). Humidity 95% or less (non-condensing),For speaker: -30 °C to 55°C (-22°F to 131°F)
Wiper:
Yes
Demist:
Yes
Material:
ADC12
Dimension:
Ø290 mm × 453.2 mm (Ø11.42" × 17.84")
Weight:
Approx. 10.5 kg (23.15 lb.)
Language:
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Tradition
EMC:
FCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014),RCM (AS/NZS CISPR 32: 2015),IC (ICES-003: Issue 7),KC (KN 32: 2015, KN 35: 2015)
Safety:
UL (UL 62368-1),CB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017),BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005),LOA (IEC/EN 60950-1)
Environment Rating:
CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No 1907/2006)
Protection:
IP67 (IEC 60529-2013),TVS 6000 V lightning protection, surge protection and voltage transient protection,IK10 (IEC 62262:2002)
Product Type:
Dome
Connectivity:
Wired
IP Rating:
IP67
Resolution:
4MP
Night Vision:
IR
