Features:
IR
Frame Rate:
Adjustable
Sensor Type:
1/3" Progressive Scan CMOS
Max. Resolution:
2688 × 1520
Min. Illumination:
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Time:
1/3 s to 1/100,000 s
Day & Night:
IR cut filter
Angle Adjustment:
Pan: -30° to 30°, tilt: 0° to 75°, rotate: 0° to 360°
Lens Type:
Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV:
2 mm, horizontal FOV 128°, vertical FOV 75°, diagonal FOV 147°;2.8 mm, horizontal FOV 104.3°, vertical FOV 55.9°, diagonal FOV 123.8°;4 mm, horizontal FOV 83.7°, vertical FOV 43.0°, diagonal FOV 100.3°
Lens Mount:
M12
Iris Type:
Fixed
Aperture:
F1.6
Depth Of Field:
2 mm: 0.6 m to ∞;2.8 mm: 1.4 m to ∞;4 mm: 1.6 m to ∞
DORI:
2 mm, D: 45 m, O: 18 m, R: 9 m, I: 4 m;2.8 mm: D: 64 m, O: 25 m, R: 13 m, I: 6 m;4 mm: D: 85 m, O: 34 m, R: 17 m, I: 9 m
Supplement Light Type:
IR
Supplement Light Range:
Up to 30 m
Smart Supplement Light:
Yes
IR Wavelength:
850 nm
Main Stream:
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720);60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream:
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360);60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream:
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360);60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360);*Third stream is supported under certain settings.
Video Compression:
Main stream: H.265/H.264/H.265+/H.264+;Sub-stream: H.265/H.264/MJPEG;Third stream: H.265/H.264;*Third stream is supported under certain settings.
Video Bit Rate:
32 Kbps to 8 Mbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR/VBR
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
1 fixed region for main stream and sub-stream
Audio Compression:
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate:
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps (MP2L2)/8-320 Kbps (MP3)/16-64 Kbps (AAC-LC)
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering:
Yes
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X (except for -W model), QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket, WebSockets
Simultaneous Live View:
Up to 6 channels
API:
Open Network Video Interface (Profile S, Profile G), ISAPI, SDK
User/Host:
Up to 32 users. 3 user levels: administrator, operator and user
Security:
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage:
NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Plug-in required live view: IE 10, IE 11;Plug-in free live view : Chrome 57.0+, Firefox 52.0+;Local service: Chrome 57.0+, Firefox 52.0+
Encryption Mode:
-W: 64/128-bit WEP, WPA-EAP/WPA2-EAP, WPA-PSK/WPA2-PSK
Wi-Fi Protocol:
-W: 802.11b: CCK, QPSK, BPSK;802.11g/n: OFDM
Frequency Range:
-W: 2.4 GHz to 2.4835 GHz
Channel Bandwidth:
-W: 20/40 MHz
Modulation:
-W: 802.11b: CCK, QPSK, BPSK;802.11g/n: OFDM
Transfer Rate:
-W: 802.11b: 11 Mbps;802.11g: 54 Mbps;802.11n: up to 300 Mbps
Wireless Range:
-W: Up to 80 m (The performance varies based on actual environment)
Image Parameters Switch:
Yes
Image Settings:
Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch:
Day, Night, Auto, Schedule
Wide Dynamic Range (WDR:
120 dB
SNR:
≥ 52 dB
Image Enhancement:
BLC, HLC, 3D DNR
Ethernet Interface:
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage:
Built-in memory card slot, support microSD card, up to 512 GB
Built-In Microphone:
Yes
Audio Support:
-IS/IWS: 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium;1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interf
Alarm:
-IS/IWS: 1 input, 1 output (max. 12 VDC, 20 mA)
Reset Key:
Yes
Basic Event:
Motion detection (human and vehicle targets classification), video tampering alarm, exception
Smart Event:
Line crossing detection, intrusion detection (support alarm triggering by specified target types (human and vehicle));Face detection
Linkage:
Upload to FTP/NAS/memory card, notify surveillance center, trigger recording, trigger capture, send email
Power Type:
-IS: 12 VDC ± 25%, 0.45 A, max. 5.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection;PoE: 802.3af, Class 3, 36 V to 57 V, 0.18 A to 0.11 A, max. 6.5 W;-IWS: 12 VDC ± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug, reverse polarity protect
Dimension:
Ø110 mm × 57.4 mm (Ø 4.3" × 2.3")
Package Dimension:
134 mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3")
Weight:
Approx. 380 g (0.8 lb.)
With Package Weight:
Approx. 615 g (1.4 lb.)
Storage Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language:
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Tradition
General Function:
Anti-flicker, heartbeat, password reset via email, pixel counter
RF:
-W: FCC ID (FCC Part 15.247(BT or 2.4G)); CE-RED (EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1(BT or 2.4G); EN 300328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G))
EMC:
FCC (47 CFR Part 15, Subpart B);CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014);RCM (AS/NZS CISPR 32: 2015);IC (ICES-003: Issue 7);KC (KN32: 2015, KN35: 2015)
Safety:
UL (UL 62368-1);CB (IEC 62368-1: 2014+A11);CE-LVD (EN 62368-1: 2014/A11: 2017)
Environment Rating:
CE-RoHS (2011/65/EU);WEEE (2012/19/EU);Reach (Regulation (EC) No 1907/2006)
Protection:
IP67 (IEC 60529-2013);IK8 (IEC 62262:2002)
Product Type:
Dome
Connectivity:
Wired
IP Rating:
IP67
Resolution:
4MP
Night Vision:
IR
