Axis C1110-E Network Cabinet Speaker
Axis C1110-E Network Cabinet Speaker The Axis C1110-E is a professional-grade network speaker engineered for enterprise security and communication sy…
Axis C1110-E Network Cabinet Speaker
$789.00
$765.99
Your recommended setup
Review items below — quantities update pricing automatically.
Item
Qty
Status
Price
Optional Add-Ons recommended
Services optional
Bundle Summary
Bundle Subtotal:
$0.00
Optional Add-Ons:
$0.00
Services:
$0.00
Total:
$0.00
Overview
SKU:
02695-001
UPC:
7331021081918
Condition:
New
Availability:
Usually ships in 24 hours
Warranty
5-year warranty
Description
Axis C1110-E Network Cabinet Speaker
The Axis C1110-E is a professional-grade network speaker engineered for enterprise security and communication systems. Delivering 96 dB of sound pressure with a built-in 7W Class D amplifier, this PoE-powered device provides crystal-clear audio for announcements, emergency alerts, and two-way communication across IP networks. Its compact aluminium casing (IP44 rated) fits seamlessly into cabinet installations while maintaining durability for continuous 24/7 operation in demanding environments.
Key Features
- 96 dB maximum sound pressure level for superior audio coverage
- 4-inch dynamic cone speaker with 1.25-inch dome tweeter for balanced frequency response (60 Hz–20 kHz)
- 140° horizontal and 90° vertical speaker coverage pattern
- Built-in 7W Class D amplifier with integrated digital signal processing
- Power over Ethernet (PoE) for simplified single-cable installation
- Dual-channel I/O with 4-pin configurable terminal blocks
- Built-in microphone (50 Hz–12 kHz) with disable option for privacy
- Two-way audio streaming with optional full-duplex echo cancellation
- Configurable front-facing RGB LED and status indicators
- IP44-rated aluminium casing; available in white or black
Technical Specifications
- Audio Processing: AXIS Audio Manager Edge for content scheduling, prioritization, and local management; supports AAC LC, G.711 PCM, G.726 ADPCM, MP3, and WAV formats
- Network Connectivity: IPv4/v6, HTTP/HTTPS, SSL/TLS, RTSP, RTP, SIP, SNMP v1/v2c/v3, DNS, NTP, and DHCP
- VoIP Integration: Full SIP support for Cisco, Avaya, and Asterisk environments; peer-to-peer or PBX integration
- Processor: NXP i.MX 8M Nano with 1GB RAM and 1GB Flash storage
- Storage: MicroSD/microSDHC/microSDXC card support
- Health Monitoring: Automatic speaker test via built-in microphone with event-driven triggers
- Operating Temperature: -30°C to 50°C; designed for harsh industrial and outdoor-adjacent environments
- Dimensions: 310mm W × 207mm H × 165mm D; 4.1 kg
Security & Compliance
Enterprise-grade security includes signed firmware, AES-XTS-Plain64 256-bit SD card encryption, OAuth 2.0 support, IEEE 802.1X authentication (EAP-TLS, PEAP-MSCHAPv2), TLS 1.2/1.3, and host-based firewall. Certified to EMC (CISPR 32 Class B), IEC/EN/UL safety standards, and ETSI EN 303 645. PVC-free construction with 51% renewable carbon-based plastic content demonstrates environmental responsibility.
Applications
Ideal for corporate offices, retail environments, educational facilities, transit stations, and critical infrastructure where integrated audio messaging, emergency notification, and two-way communication are essential. The cabinet-mount design and PoE efficiency make it perfect for expanding existing IP surveillance deployments without additional infrastructure investment.
Karl Wilson
The C1110-E represents Axis' mature approach to networked audio—moving audio distribution from analog to IP-managed systems. The built-in microphone and two-way capability with echo cancellation enable genuine intercom scenarios, not just broadcast. AXIS Audio Manager Edge (included) eliminates the need for separate servers; organizations can schedule announcements, prioritize emergency messages, and monitor speaker health locally.
The 7W amplifier is modest but sufficient for cabinet mounting in medium-sized rooms; larger deployments should leverage multiple units or consider AXIS Audio Manager Pro for distributed systems. SIP integration is comprehensive, supporting major PBX vendors without proprietary gateways. The IP44 rating and -30°C operating range allow semi-outdoor cabinet placement.
Security posture is strong—signed firmware, certificate-based authentication, and encryption cover both edge and network threat vectors. The 5-year warranty and 51% bio-based plastic construction align with enterprise sustainability mandates. For IT teams, open API support and ACAP integration simplify custom alerting workflows.
Compared to legacy analog speakers, the PoE model reduces cabling complexity and enables granular event-driven triggers (IP blocked, ring power overcurrent, etc.). Recommended for organisations standardising on Axis infrastructure.
Specifications
Enclosure:
Two-way bass-reflex type Speaker components: 4-inch dynamic cone speaker, 1.25- inch dome tweeter
Max sound pressure level:
96 dB
Frequency response:
60 Hz - 20 kHz
Coverage pattern:
Horizontal speaker coverage 140° Vertical speaker coverage 90°
Audio input/output:
Built-in microphone (can be disabled)
Built-in microphone specification:
50 Hz - 12 kHz
Amplifier description:
Built-in 7 W Class D amplifier
Digital signal processing:
Built-in and pre-configured
AXIS Audio Manager Edge:
Built in: – Content management for music and live/pre-recorded announcements. – Scheduling to decide when and where to play specific content. – Content prioritization to ensure urgent messages interrupt the schedule.
AXIS Audio Manager Pro:
For larger and more advanced systems. Sold separately. See separate datasheet for specifications.
AXIS Audio Manager Center:
AXIS Audio Manager Center is a cloud service for remote access and management of multi-site systems.
Audio streaming:
One-way/two-way with optional full-duplex echo cancellation. Mono.
Audio encoding:
AAC LC 8/16/32/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Axis µ-law 16 kHz, WAV, MP3 in mono/stereo from 64 kbps to 320 kbps. Constant and variable bit rate. Sampling rate from 8 kHz up to 48 kHz.
Model:
NXP i.MX 8M Nano
RAM:
1024 MB RAM, 1024 MB Flash
Network protocols:
IPv4/v6a, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, NTCIP, SIP (Cisco, Avaya, Asterisk)
Application Programming Interface:
Open API for software integration, including VAPIX®, One-click cloud connection, AXIS Camera Application Platform (ACAP).
VoIP:
Support for Session Initiation Protocol (SIP) for integration with Voice over IP (VoIP) systems. Peer to peer or integrated with SIP/PBX. Tested with: SIP client such as Cisco, Bria and Grandstream and PBX suppliers such as Cisco and Asterisk.
Health monitoring:
Auto Speaker Test (verification via built-in microphone)
Event conditions:
Application Audio: audio clip playing, speaker test result Call: state, state change Device status: IP address blocked, IP address removed, live stream active, network lost, new IP address, ring power overcurrent protection, system ready
Event actions:
Audio: run automatic speaker test Audio clips: play, play while the rule is active, stop playing I/O: toggle I/O once, toggle I/O while the rule is active Light and siren: run light profile, run light profile while the rule is active, stop activities
Built-in installation aids:
Test tone verification and identification
EMC:
CISPR 24, CISPR 35, CISPR 32 Class B, EN 55024, EN 55035, EN 55032 Class B, EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-6-4 Australia/New Zealand: RCM AS/NZS CISPR 32 Class B Canada: ICES-3(B)/NMB-3(B) Japan: VCCI Class B
Safety:
CAN/CSA C22.2 No. 62368-1, CAN/CSA-C22.2 No. 60950-22, IEC/EN/UL 62368-1, IEC/EN/UL 60950-22, KC-Mark
Environment Rating:
IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP44b, Nema 250 3R
Features:
ETSI EN 303 645
Edge security:
Software: Signed firmware, brute force delay protection, digest authentication and OAuth 2.0 RFC6749 OpenID Authorization Code Flow for centralized ADFS account management, password protection, AES-XTS-Plain64 256bit SD card encryption
Network security:
IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2), IEEE 802.1AR, HTTPS/HSTS, TLS v1.2/v1.3, Network Time Security (NTS), X.509 Certificate PKI, host-based firewall
Documentation:
AXIS OS Hardening Guide Axis Vulnerability Management Policy Axis Security Development Model AXIS OS Software Bill of Material (SBOM)
Substance control:
PVC free, BFR/CFR free in accordance with JEDEC/ECA Standard JS709 RoHS in accordance with EU RoHS Directive 2011/65/EU/ and EN 63000:2018 REACH in accordance with (EC) No 1907/2006. For SCIP UUID, see echa.europa.eu
Materials:
Renewable carbon-based plastic content: 51% (recycled: 0%, bio-based: 51%, carbon capture based: 0%) Screened for conflict minerals in accordance with OECD guidelines To read more about sustainability at Axis, go to axis.com/about-axis/sustainability
Environmental responsibility:
axis.com/environmental-responsibility Axis Communications is a signatory of the UN Global Compact, read more at unglobalcompact.org
Casing:
Aluminium casing, IP44 rated Colors: white, black For repainting instructions, go to axis.com/products/axis-c1110-e/support For information about the impact on warranty, go to axis.com/warranty-implication-when-repainting.
Power Type:
PoE
Connectors:
RJ45 10BASE-T/100BASE-TX PoE I/O: 4-pin 2.5 mm terminal block for 2x supervised configurable I/Os
LED indicators:
Status LED, configurable front-facing RGB LED
Storage Capacity:
Support for microSD/microSDHC/microSDXC card
Reliability:
Designed for 24/7 operation.
Operating Temperature:
-30 °Cto 50 °C (-22 °Fto 122 °F) Humidity 10–100% RH (condensing)
Storage conditions:
-40 °Cto 65 °C (-40 °Fto 149 °F) Humidity 5–95% RH (non-condensing)
Dimensions:
Height: 207 mm (8.15 in) Width: 310 mm (12.2 in) Length: 165 mm (6.50 in)
Weight:
4100 g (9.04 lbs)
Box content:
Speaker, installation guide, terminal block connector, connector guard, cable gaskets, owner authentication key
Optional accessories:
AXIS C8310 Volume Controller, AXIS Surveillance Cards For more accessories, see axis.com
System tools:
AXIS Site Designer, AXIS Device Manager, product selector, accessory selector, lens calculator Available at axis.com
Video management software:
AXIS Companion, AXIS Camera Station, video management software from Axis’ Application Development Partners available on axis.com/techsup/software
Languages:
English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Polish, Traditional Chinese, Dutch, Czech, Swedish, Finnish, Turkish, Thai, Vietnamese
Warranty:
5-year warranty
Product Type:
Speaker
Connectivity:
Wired
