Altronix T3MK77F16QFM 16-Output 20A Power Supply

Altronix T3MK77F16QFM Power Supply/Charger

The Altronix T3MK77F16QFM is a 16-output power supply and charger unit designed for distributed power delivery in security and access control installations. This chassis-mounted unit provides reliable 115VAC input power conversion with integrated battery backup management, making it suitable for systems requiring redundancy and failover protection.

Overview

The T3MK77F16QFM delivers centralized power distribution across 16 independent outputs, each capable of supporting cameras, access points, and auxiliary devices typical in mid-to-large security deployments. The 20-ampere capacity allows for flexible load allocation across multiple circuits without exceeding system ratings. Built-in battery supervision and charging circuits enable automatic switchover to backup power during AC loss events, critical for 24/7 surveillance and access control continuity.

Key Features

• 16 independent power outputs for distributed load management
• 20-ampere maximum current rating supports high-draw camera arrays and multi-device circuits
• 115VAC input voltage compatibility with North American standard wall power
• Integrated battery backup supervision and automatic switchover on AC loss
• Charger circuitry for sealed lead-acid (SLA) battery charging and float maintenance
• Modular output design allows independent circuit isolation and control
• Chassis-mount form factor for secure installation in equipment racks or control rooms
• Thermal protection and overcurrent limiting on output circuits

Integration & Compatibility

The T3MK77F16QFM integrates into security systems requiring distributed power architecture. Each of the 16 outputs can be independently fused and monitored, enabling integration with access control panels, camera DVR/NVR systems, and IP device PoE injectors. The battery backup supervision function works with standard SLA batteries, common in professional security installations where 4–8 hours of backup runtime is required. System integrators can configure output circuits individually, making the unit adaptable to both analog CCTV and IP-based hybrid deployments.

Installation Considerations

The unit requires standard 115VAC power input and should be installed in a controlled environment with adequate ventilation. Battery terminals are provided for external SLA battery connection; sizing depends on circuit load and required runtime. Each output circuit should be individually fused at the load or at the power supply terminals to protect connected equipment. For installations requiring remote monitoring of power status or battery health, integration with the facility's central alarm or management system is recommended. Proper grounding and surge protection at the AC inlet help protect against transient events.

Jerry Tildsen

During a recent multi-site security upgrade, I evaluated the Altronix T3MK77F16QFM for a distributed camera and access control rollout. The 16-output architecture and 20-ampere capacity proved well-suited to mid-scale deployments where centralized power management from a single chassis reduces infrastructure complexity and simplifies troubleshooting.

Technical Highlights:

• Distributed Output Design: The 16 independent outputs mean each circuit can be individually protected and monitored, reducing the risk of a single point of failure affecting the entire system.
• Battery Backup Integration: Built-in charger and supervision circuits simplify integration with SLA batteries, automating the switchover process and eliminating the need for external charge controllers in many applications.
• Load Flexibility: At 20 amperes total, the unit can support mixed loads—analog cameras at 0.5–1 A per channel, IP PoE devices at 2–6 A, and access control modules at variable draw—without requiring separate power conditioning per circuit.

Deployment Considerations:

• Calculate total connected load carefully; in practice, the 20A rating is shared across all 16 outputs, so simultaneous high-draw devices must be accounted for during circuit design.
• Battery backup capacity should be right-sized for facility requirements; undersizing the battery defeats the backup function, while oversizing increases footprint and cost unnecessarily.

For integrators managing multi-building or multi-floor security deployments, the T3MK77F16QFM offers a proven, straightforward approach to distributed power—no exotic features, just reliable architecture that scales from small commercial sites to larger installations with multiple units.
