Altronix AL600RLB 6A 12/24VDC Power Supply Board

Altronix AL600RLB 6A 12/24VDC Power Supply Board

The Altronix AL600RLB is a compact board-form power supply rated for 6A continuous output at selectable 12VDC or 24VDC. It converts 115VAC 60Hz input (maximum 3.5A) and supports sealed lead acid or gel-type battery backup for access control, alarm, and fire safety systems. The AL600RLB is UL294, UL603, UL1481, and cUL approved for multi-application use in security infrastructure.

Key Features

• Single output at 6A continuous supply current
• Selectable 12VDC or 24VDC output voltage
• AC Failure supervision with Form C relay output
• Battery backup supervision with Form C relay and LED indicator
• Low Battery supervision with LED status indication
• Compact 7.1" × 4.5" × 2" board dimensions
• 115VAC 60Hz input rated at 3.5A maximum
• Supports sealed lead acid or gel-type backup batteries (sold separately)

Applications

• Access control system power distribution
• Burglar alarm system backup power
• Fire alarm system UPS requirements
• Embedded security panel power conditioning

Specifications

• Input: 115VAC 60Hz, 3.5A max
• Output: 6A continuous at 12VDC or 24VDC (selectable)
• Board dimensions: 7.1" × 4.5" × 2" (180.3mm × 114.3mm × 50.8mm)
• Operating temperature: 0°C to 49°C (32°F to 120°F)
• Approvals: UL294, UL603, UL1481, cUL CSA C22.2 No.205-M1983
• Battery backup: Sealed lead acid or gel type (sold separately)
• Warranty: Lifetime Limited Warranty
