Hanwha LND-6072R 2MP Day/Night WDR 1080p 30FPS Varifocal IR Outdoor Bullet IP Camera

The Hanwha LND-6072R 2MP IR Dome IP Camera redefines surveillance excellence, catering to the exacting demands of businesses and IT environments. Merg…

Add to cart for sale price
Ships same business day
In stock

Quantity:

Adding to cart… The item has been added
Compatibility guidance available for your deployment
Certified experts for pre and post-sales support
Authorized sourcing and documentation support
Shipping and lead-time confirmation before install

Bryan

Talk to Bryan

200+ hrs training • U.S - based

Certified Expert • 877-277-7147

Hanwha LND-6072R 2MP Day/Night WDR 1080p 30FPS Varifocal IR Outdoor Bullet IP Camera

Your recommended setup

Review items below — quantities update pricing automatically.

Item Qty Status Price

Bundle Summary

Bundle Subtotal: $0.00
Optional Add-Ons: $0.00
Services: $0.00
Total: $0.00

Overview

SKU: LND-6072R
UPC: 8801089170040
Condition: New
Availability: No Longer Available
Warranty 3-year warranty
Description

The Hanwha LND-6072R 2MP IR Dome IP Camera redefines surveillance excellence, catering to the exacting demands of businesses and IT environments. Merging cutting-edge technology with robust construction, this camera offers unparalleled monitoring capabilities both indoors and outdoors. With its advanced features and intuitive design, the Hanwha LND-6072R is a testament to Hanwha's commitment to delivering superior security solutions.

Key Features:

  • 2 Megapixel Clarity: Experience unmatched clarity with the camera's 2-megapixel (1920 x 1080) resolution, ensuring every detail is captured with precision.

  • Versatile Varifocal Lens: The 3.2 ~ 10mm varifocal lens provides flexibility and adaptability to various indoor settings, offering a wide 101.6° to 31.3° field of view.

  • Advanced Codec Support: Benefit from efficient data management with support for both H.264 and MJPEG codecs, ensuring optimal video compression without sacrificing quality.

  • Day & Night Monitoring: Seamlessly transition between day and night modes with the Infrared Cut Filter Removal (ICR) feature, ensuring clear and continuous surveillance in all lighting conditions.

  • Outstanding Wide Dynamic Range (WDR): The camera boasts an impressive 120dB WDR, which expertly manages challenging lighting situations, capturing accurate images in high-contrast environments.

  • Tampering and Motion Detection: Enhance security with built-in tampering and motion detection capabilities, promptly alerting you to any unauthorized activity.

  • Local Storage Convenience: With a Micro SD/SDHC memory slot supporting cards up to 32GB, you have the option of local storage for important footage.

  • Power over Ethernet (PoE): Simplify installation with PoE support, delivering both power and data through a single Ethernet cable.

  • Hallway View Mode: Maximize surveillance coverage in narrow corridors or hallways with the dedicated hallway view mode, ensuring no detail goes unnoticed.

  • WiseStream II Technology: Experience intelligent bandwidth optimization with WiseStream II technology, which reduces storage and bandwidth costs while maintaining high video quality.

  • IR Illumination: The camera features built-in IR LEDs, offering a night vision range of up to 20 meters (approximately 65 feet) for round-the-clock surveillance.

  • Sleek White Design: The camera's white body design seamlessly blends into indoor environments, providing discreet yet powerful surveillance.

Compatibility:

The Hanwha LND-6072R 2MP IR Dome Camera is compatible with a variety of network video recorders (NVRs) and surveillance systems, ensuring seamless integration into your existing setup.

Specifications:

  • Camera Type: IR Dome Camera (Indoor)
  • Resolution: 2 Megapixel (1920 x 1080)
  • Frame Rate: 30fps (H.264)
  • Codec Support: H.264, MJPEG
  • Varifocal Lens: 3.2 ~ 10mm
  • Wide Dynamic Range: 120dB WDR
  • Memory Slot: Micro SD/SDHC (Max. 32GB)
  • IR Viewable Length: 20m (Approximately 65 feet)

Package Contents:

  • Hanwha LND-6072R 2MP IR Dome IP Camera
  • Mounting screws and hardware
  • Installation guide
  • Waterproof gasket
  • Allen key

Summary: The Hanwha LND-6072R 2MP IR Dome IP Camera stands out as a premier solution for businesses seeking robust surveillance capabilities. With its advanced features, including high-resolution imaging, night vision, and intelligent analytics, this camera ensures comprehensive monitoring in any environment. Backed by its seamless integration and user-friendly interface, the Hanwha LND-6072R offers unmatched performance, setting a new standard in IP surveillance technology.

Specifications
Frame Rate: 30fps
Imaging Device: 1/2.8" CMOS
Resolution: 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360
Max. Framerate: H.265/H.264: Max. 30fps/25fps(60Hz/50Hz); MJPEG: Max. 10fps(@2MP Max. 2fps)
Min. Illumination: Color: 0.03Lux(F1.6, 1/30sec); BW : 0Lux (IR LED on)
Focal Length (Zoom Ratio: 3.2~10mm(3.1x) manual varifocal
Max. Aperture Ratio: F1.6(Wide)~F2.9(Tele)
Angular Field of View: H: 109°(Wide)~33°(Tele); V: 58°(Wide)~18°(Tele); D: 132°(Wide)~38°(Tele)
Min. Object Distance: 0.5m(1.64ft)
Focus Control: Manual
Lens Type: DC auto iris
Pan / Tilt / Rotate Range: 0°~350° / 0°~67° / 0°~355°
Camera Title: Displayed up to 15 characters
Day & Night: Auto(ICR)
Backlight Compensation: BLC, WDR, SSDR
Wide Dynamic Range: 120dB
Digital Noise Reduction: SSNR
Motion Detection: 4ea, rectangler zones
Privacy Masking: 6ea, rectangular zones
Gain Control: Low / Middle / High
White Balance: ATW / AWC / Manual / Indoor / Outdoor
LDC: Support
Electronic Shutter Speed: Minimum / Maximum / Anti flicker (2~1/12,000sec)
Video Rotation: Flip, Mirror, Hallway view(90°/270°)
Analytics: Motion detection, Tampering
Alarm Triggers: Analytics
Alarm Events: When alarm trigger occurred; - File upload(image) : e-mail/FTP; - Notification : e-mail; - Recording : SD/SDHC/SDXC or NAS recording at event triggers
Light Type: IR LED (850nm)
Light Viewable Length: 20m(65.62ft)
Ethernet: RJ-45(10/100BASE-T)
Video Compression: H.264: Main/Baseline/High, MJPEG
Smart Codec: WiseStreamⅡ
Bitrate Control: H.264: CBR or VBR; MJPEG: VBR
Streaming: Unicast(6 users) / Multicast; Multiple streaming (Up to 3 profiles)
Protocol: IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour
Application Programming Interface: ONVIF Profile S/G/T; SUNAPI(HTTP API)
OS / Firmware Protect: Firmware encryption
User authentication: Digest Authentication, Prevent brute-force attack
Network authentication: 802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
Secure Communication: HTTPS, SRTP, WSS(Websocket secure)
Access Control: Access control based on IP address
Data Protect: Authentication information encryption, ZIP compression encryption
Audit: User Access/System/Event log management
Device ID: Device Certificate(Hanwha Private Root CA)
Secure Storage: SDcard partition encrypt
Webpage Language: English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch
Edge Storage: Micro SD/SDHC 1slot 32GB
RAM: 512MB RAM, 256MB Flash
Operating Temperature / Humidity: -10°C~+55°C(+14°F ~ +131°F) / 0~90% RH
Storage Temperature / Humidity: -30°C ~ +55°C(-22°F ~ +131°F) / Less than 90% RH
Input Voltage: PoE(IEEE802.3af, Class3)
Power (Max: Max 6.4W, Typical 5.0W
Color / Material: White / Plastic
RAL Code: RAL9003
Product Dimensions / Weight: ø119.8x98.8mm(ø4.72x3.89"), 315g
Hanging Mount (Dome: SBP-122HMW
Detect (25PPM/ 8PPF: Wide: 27.4m(89.85ft) / Tele: 128.8m(422.56ft)
Observe (63PPM/ 19PPF: Wide: 11.0m(35.94ft) / Tele: 51.5m(169.02ft)
Recognize (125PPM/ 38PPF: Wide: 5.5m(17.97ft) / Tele: 25.8m(84.51ft)
Identify (250PPM/ 76PPF: Wide: 2.7m(8.99ft) / Tele: 12.9m(42.26ft)
