Image Sensor:
1/2.5" Progressive Scan CMOS
Max. Resolution:
3840 × 2160
Min. Illumination:
Color: 0.056 Lux @ (F2.0, AGC ON), 0 Lux with IR
Shutter Time:
1 s to 1/100,000 s
Day & Night:
ICR Cut
Angle Adjustment:
P: -90 to 90°; T: 0 to 60° (2.8mm), 0 to 70° (4/6mm); R: 0 to 355°
Focal Length & FOV:
2.8mm @ F2.0, horizontal FOV 103°, vertical FOV 53°, diagonal FOV 124°;4 mm @ F2.0, horizontal FOV 79°, vertical FOV 41°, diagonal FOV 94°;6 mm @ F2.0, horizontal FOV 50°, vertical FOV 27°, diagonal FOV 58°
Lens Mount:
M12
Aperture:
F2.0
DORI:
2.8 mm: D: 105.4 m, O: 41.8 m, R: 21.1 m, I: 10.5 m;4 mm: D: 123.5 m, O: 49.0 m, R: 24.7 m, I: 12.3 m;6 mm: D: 181.5 m, O: 72.0 m, R: 36.3 m, I: 18.1 m
Supplement Light Range:
Up to 10 m
Supplement Light Type:
IR
Smart Supplement Light:
Yes
IR Wavelength:
850 nm
Main Stream:
50 Hz: 12.5 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720);60 Hz: 15 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream:
50 Hz: 12.5 fps (640 × 480, 704 × 576);60 Hz: 15 fps (640 × 480, 704 × 480)
Video Compression:
H.265/H.264/MJPEG
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR/VBR
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
4 fixed regions for each stream
Audio Type:
-S: Stereo
Audio Compression:
-S: G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate:
-S: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 60Kbps (MP2L2)/250 Kbps (PCM)
Audio Sampling Rate:
-S: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering:
-S: Yes
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Simultaneous Live View:
Up to 20 channels
API:
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
User/Host:
Up to 32 users;3 user levels: administrator, operator, and user
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTT
Network Storage:
NAS (NFS, SMB/CIFS)
Client:
iVMS-4200, Hik-Connect
Web Browser:
Plug-in required live view: IE8+;Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+;Local service: Chrome 41.0+, Firefox 30.0+
Image Parameters Switch:
Yes
Image Settings:
Rotate, saturation, brightness, contrast, sharpness, white balance adjustable by client software or web browser;*Rotate and perimeter protection events (line crossing detection, intrusion detection, region entrance detection, region exiting detection
Day/Night Switch:
Day, Night, Auto, Schedule, Triggered by Alarm In (-S)
Wide Dynamic Range (WDR:
120 dB
Image Enhancement:
BLC, HLC, Defog, EIS, 3D DNR
Privacy Mask:
Yes
Picture Overlay:
LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format
Ethernet Interface:
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage:
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Audio:
Without -S: 2 built-in mics;-S: 2 built-in mics, 1 line in, 1 line out
Alarm:
-S: 1 input, 1 output (max. 36 VDC, 30mA)
RS-485:
-S: 1 RS-485 interface, half duplex
Reset Key:
Yes
Basic Event:
Motion detection,video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event:
Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection;Scene change detection, audio exception detection
Linkage:
Upload to FTP/NAS/memory card, send email, notify surveillance center
Power:
12 VDC, 0.9 A, max. 11 W, Ø5.5 mm coaxial power plug;PoE: 802.3af, 36 V to 57 V, 0.3 A to 0.2 A, max. 11 W
Dimension:
164.3 × 84.6 × 67.4 mm (6.5" × 3.3" × 2.7")
Package Dimension:
227 × 172 × 125 mm (8.9" × 6.8" × 4.9")
Weight:
Approx. 770 g (1.7 lb.)
With Package Weight:
Approx. 1053 g (2.3 lb.)
Startup And Operating Conditions:
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
General Function:
Mirror, password protection, watermark, one-key reset, anti-flicker, heartbeat
Language:
32 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Tradition
EMC:
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
Safety:
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
Environment:
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection:
Ingress protection: IP67, IK10
